Self Feeder/Tilting Cup Feeder/ Vibrating Feeder/Vibratory Feeder / Vibrofeeder
Virbrating feeder is disposed in front of primary breaker,at the same time it will continuously convey big block of material,remove off the dirt and impurity. To control the feeding quantity and subsequent breaking,match the processing capacity of screening production line,and make the series to be necessary equipment for ensuring the quality and quantity in breaking and screening production line.
| Models | Max Feed Size (mm) | Crushing Capacity (t/h) | Electric Motor Power (KW) | Installation Slope | Weight (kg) | Size of Funnel (mm) | Overall Dimensions (L×W×H) |
| GZD-850×3000 | 400 | ~120 | 3.7×2 | 5° | 3607 | 850×3000 | 3110×1800×1600 |
| GZD-960×3800 | 500 | ~150 | 5.5×2 | 5° | 3980 | 1000×3600 | 3850×1950×1630 |
| GZD-1100×4200 | 580 | ~240 | 5.5×2 | 5° | 4170 | 1100×4200 | 4400×2050×1660 |
| GZD-1100×4900 | 580 | ~280 | 7.5×2 | 5° | 4520 | 4900×1100 | 5200×2050×1700 |
| GZD-1300×4900 | 650 | ~450 | 11×2 | 5° | 5200 | 4900×1300 | 5200×2350×1750 |
Model | Screen Surface Layers | Screen Size
(mm) | Sieve Size
(mm) | Max Feed Size (mm) | Handling Capacity
(m3/h) | Vibration Frequency
(r/min) | Double Amplitude | Motor Power (kw) | Weight (kg) | Screen Surface Inclination | Screen Surface Specification (mm) |
YK1236 | 1 | 4.3 | 1-100 | 200 | 30-160 | 970 | 8 | 5.5 | 3210 | 20o | 1200x3600 |
2YK1245 | 2 | 5.4 | 3-50 | 200 | 32-180 | 970 | 7 | 11 | 4320 | 20o | 1200x4500 |
YK1530 | 1 | 5.25 | 3-50 | 200 | 34-200 | 970 | 8 | 11 | 3355 | 20o | 1500x3000 |
YK1545 | 1 | 6.75 | 3-50 | 300 | 44-258 | 970 | 8 | 11 | 3900 | 20o | 1500x4500 |
4YK1548 | 4 | 7.2 | 3-100 | 300 | 47-275 | 730 | 8 | 18.5 | 7090 | 20o | 1500x4800 |
YK1848 | 1 | 8.8 | 3-100 | 400 | 56-330 | 755 | 11 | 15 | 7122 | 20o | 1800x4800 |
3YK1848 | 3 | 8.8 | 3-100 | 400 | 56-330 | 970 | 7 | 22 | 6935 | 20o | 1800x4800 |
YK1860 | 1 | 10.8 | 3-100 | 400 | 66-630 | 970 | 8 | 15 | 7222 | 20o | 1800x6000 |
YK2160 | 1 | 12.6 | 3-100 | 400 | 81-720 | 970 | 8 | 18.5 | 8860 | 20o | 2100x6000 |
2YK2160 | 2 | 12.6 | 3-100 | 400 | 81-720 | 970 | 8 | 30 | 9240 | 20o | 2100x6000 |
YK2460 | 1 | 14.4 | 5-150 | 400 | 150-810 | 730 | 8 | 22 | 6200 |
|
