Condole Type Double Deck Vibrating Screen

Specifications

mobile vibrating screen
simple structure, reliable operation and maintenance convenience, the user hanging when ordering please



YA,SZZ Vibrating Screen



YA, SZZ shaker widely used in mining, smelting, building material, highway, railway, water conservancy and chemical industry and many other sectors of the medium-grained materials, grading, dewatering, de-de or referred mud and operations.

This series of vibrating screen features are: simple structure, reliable operation and maintenance convenience, the user hanging when ordering please specify type and seat type



Model	Screen Layers	Screen Area	Feed size	Capacity	Opening size	Frequency	Power	Weight
	Layers	m2	mm	t/h	mm	r/min	kw	Kg
600/1200	1	1.1	40	10-20	1-15	1000	2.2	350
600/1200	2	1.1	40	10-20	1-15	1000	2.2	360
900/1800	1	1.62	60	20-25	1-25	1000	2.2	550
900/1800	2	1.62	60	20-30	1-25	1000	3	620
1250/2500	1	3.13	100	150	3-30	850	5.5	1100
1250/2500	2	3.13	100	150	3-30	850	5.5	1300
1500/3000	1	4.5	150	220	5-40	800	7.5	2100
1500/3000	2	4.5	150	250	5-40	800	7.5	2300
1800/4800	1	7.5	200	450	6-50	360	15	6000
1800/4800	2	7.5	200	500	6-50	360	15	6300
