Specifications
small experimantal grindingShicheng Oasis Mineral Equipment Manufacturing Co., LTD
Tel:0086-13697077005Fax:0086-797-57913
The experiment of grinding equipment, grinding time can be arbitrarily set, but also can be used in dry, wet grinding, using frequency conversion technology, speed range is wide, abrasive, mixing and even everything easy installation without foundation treatment, low noise, no dust pollution, to facilitate the work of cleaning, polishing sealing performance is good, ordinary ore optional experimental study and manual re-sanding of ore used in the rod mill more appropriate.
The grinding equipment, a large amount of feeding, discharging, cylinder power control, without manual, grinding time can be arbitrarily set
Model | Uite | XMQ150/50 | XMQ240/90 | XMQ350/160 |
Drum size | mm | 150/50 | 240/90 | 350/160 |
Volume | L | 1 | 6.25 | 21.58 |
Capacity | g | 200 | 1000 | 4000 |
Feed size | mm | 3 | 3 | 3 |
Rarticle size | mm | 0.074 | 0.074 | 0.074 |
Drum speed | r/min | 110-114 | 94-98 | 60-64 |
rower | kw | 0.25 | 0.55 | 1.1 |
Overall dimensions | mm | 915/530/1160 | 1050/640/1164 | 700/575/1190 |
Weighe | kg | 91 | 170 | 300 |
The experiment of grinding equipment, grinding time can be arbitrarily set, but also can be used in dry, wet grinding, using frequency conversion technology, speed range is wide, abrasive, mixing and even everything easy installation without foundation treatment, low noise, no dust pollution, to facilitate the work of cleaning, polishing sealing performance is good, ordinary ore optional experimental study and manual re-sanding of ore used in the rod mill more appropriate.
The grinding equipment, a large amount of feeding, discharging, cylinder power control, without manual, grinding time can be arbitrarily set
Model | Uite | XMQ150/50 | XMQ240/90 | XMQ350/160 |
Drum size | mm | 150/50 | 240/90 | 350/160 |
Volume | L | 1 | 6.25 | 21.58 |
Capacity | g | 200 | 1000 | 4000 |
Feed size | mm | 3 | 3 | 3 |
Rarticle size | mm | 0.074 | 0.074 | 0.074 |
Drum speed | r/min | 110-114 | 94-98 | 60-64 |
rower | kw | 0.25 | 0.55 | 1.1 |
Overall dimensions | mm | 915/530/1160 | 1050/640/1164 | 700/575/1190 |
Weighe | kg | 91 | 170 | 300 |
