Specifications
Shicheng Oasis Mineral Equipment Manufacturing Co., LTDTel:0086-13697077005Fax:0086-797-5791369
Technical Parameter of laboratory XMB Rod Mill
XMB Rod Mill is applicable to lab.for wet fine grinding of ore and other materials.Steel ball may be used instead of steel rod in the ball mill.In rod grinding,fine product particle fractions are relatively uniform with rare occurrence of overgrinding and high efficiency.In general,rod grinding is introduced for test on ore for separability and manual fine grinding of placer materials.The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Resources,in compliance with the Industrial standards
The grinding equipment, a large amount of feeding, discharging, electric cylinder control, no manual, can also be replaced by steel balls to use bar
Model | Uite | XMB160/200 | XMB200/400 | XMB240/300 | |||||||||
Cylinder size | mm | 160/200 | 200/240 | 240/300 | |||||||||
Volume | L | 4.02 | 7.5 | 13.57 | |||||||||
Capacity | g | 300-800 | 500-1000 | 1000-5000 | |||||||||
Feed size | mm | 2 | 2 | 3 | |||||||||
Rarticle size | mm | 0.074 | 0.074 | 0.074 | |||||||||
Drum speed | r/min | 120 | 110 | 96 | |||||||||
rower | kw | 0.25 | 0.55 | 0.55 | |||||||||
The grinding medium | Steel bar | diameter | Mm | 18 | 20 | 15 | 18 | 22 | 15 | 18 | 22 | ||
The length | Mm | 185 | 225 | 286 | |||||||||
quantity | The root | 10 | 9 | 17 | 9 | 9 | 33 | 13 | 6 | ||||
weight | Kg | 3.55 | 4.09 | 4.9 | 4.2 | 4.9 | 12.7 | 7.48 | 5.0 | ||||
gangqiu | diameter | mm | 20 | 25 | 30 | 20 | 25 | 30 | 20 | 25 | 30 | ||
The length | a | 100 | 26 | 5 | 136 | 52 | 29 | 290 | 115 | 37 | |||
weight | kg | 3.3 | 1.7 | 0.56 | 4.4 | 3.3 | 3.7 | 9.57 | 7.37 | 4.1 | |||
Overall dimensions | mm | 1052/530/1160 | 1052/615/1160 | 1052/615/1160 | |||||||||
Weighe | kg | 91 | 150 | 162 | |||||||||
