HOT SALE!!! VMC850 Vertical Machining Center
Specification of Machining Center
Table travel (X,Y,Z) | mm | 850X500X500 |
Table size | mm | 1000X510 |
Number/Width/Distance of T-slot | mm | 5-18-100 |
Max.load of table | kg | 500 |
Distance from spindle nose to table surface | mm | 150-650 |
Distance from spindle axis to vertical guideway | mm | 540 |
Taper of spindle |
| BT40 |
Spindle speed range | rpm | 40-6000 |
Spindle motor power | kW | (AC servo ) 7.5 |
Rapid feed speed (X,Y,Z) | mm/min | 18000 |
Feed speed (X,Y,Z) | mm/min | 2-4000 |
| Tool magazine capability | qty | 16 |
| Max. weight oo tool | kg | 8 |
| Max. dimension of tool | mm | Φ 130X250 |
Positioning accuracy | mm | ±0.015 |
Repeat positioning accuracy | mm | ±0.0075 |
Min. time of tool change | sec | 3 |
Overall dimension | mm | 2500×2360×2300 |
Machine weight | kg | 4750 |
Standard Equipment of Machining Center
Max spindle speed 8000rpm ( fixed to 6000 rpm before delivery )
Tool changer is BT40x16 Umbrella type tool magazine,
Linear guideway,
Whole Protection,
Automatic Lubrication unit,
Quazrt Lamb,
Coolant supply system,
Elecric handwheel.
Optional Equipment of Machining Center
Electromagnetic Doorlock
Disc-type tool magazine capability 16 tools
Automatic Chained chip conveyor
About Our Company
We are one of biggest manufacturer of producing Machining Center, CNC milling machine, Universal Milling Machine, CNC Lathe, etc in China. Our factory entered the top 8 machine tool builders in the world. Our machining centers are sold to more than 100 countries and regions worldwide.
.
...
