Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > HOT Sales !!! X6332Z Drilling and Milling Machine
US$ 1 - 8,900
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
MACH
Payment & Shipping
Payment Methods:
Port of Shipment:
Main Port China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CDL6241 DMTG Horizontal Lathe MachineUS$ 5,650 - 6,350MOQ: 1 Unit -
CDS6266C DMTG Gap-Bed Lather MachineUS$ 9,500 - 12,000MOQ: 1 Unit
-
CW6280E DMTG Universal Lather MachineUS$ 16,500 - 33,000MOQ: 1 Unit
-
CDS6250B DMTG Gap-Bed Lather MachineUS$ 5,000 - 10,000MOQ: 1 Unit
-
XZ7550CW Milling/ Drilling MachineUS$ 1 - 20,000MOQ: 1 Unit
Condition
New
Place of Origin
Shandong, China
Brand Name
MACH
Model Number
X6332Z
Type
Vertical
CNC or Not
Normal
Voltage
380V
Power(W)
2.2KW
Dimension(L*W*H)
1710x1720x2330mm
Weight
2000KGS
Certification
CE
Warranty
One Year
After-sales Service Provided
Engineers available to service machinery overseas
X6332Z Drilling and Milling Machine
Technical Data
| SPECIFICATION | UNIT | X6332Z |
| TABLE SIZE | MM | 1320×320 |
| SPINDLE SPEED RANGE | R/MIN | 90-2000(V),38-1310(H) |
| SPINDLE TAPER | ISO40 | |
| TABLE TRAVEL | MM | 800(750) ×300 |
| MAX. DRILLING DIA. | MM | 50 |
| MAX. AUTOMATICAL DRILLING DIA. | MM | 14(CAST IRON) |
| DISTANCE FROM SPINDLE NOSE TO TABLE SURFACE | MM | 180-580 |
| DISTANCE BETWEEN SPINDLE AXIS AND COLUMN SURFACE | MM | 200-780 |
| SPINDLE TRAVEL | MM | 120 |
| MAIN MOTOR | KW | 2.2(V/H) |
| OVERALL DIMENSION(L×W×H) | MM | 1710×1720×2330 |
| NET WEIGHT | KG | 2000 |
Characteristic:
1. Rectangular table guideways with high stability.
2. Hardened and ground table surface.
3. Automatic feeds on X, Y axes, motorized lifting and lowering of table on Z axis
4. Headstock swivels +/- 45°.
About our company:
We are one of biggest manufacturer of producing CNC Milling Machine, Vertical machining Center, Universal Milling Machine, CNC Lathe,etc in China. We entered the top 8 machine tool builders in the world. Our CNC Milling Machine sell to more than 100 countries and regions worldwide.
....
