Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CDS6266C DMTG Gap-Bed Lather Machine

CDS6266C DMTG Gap-Bed Lather Machine

Name: CDS6266C DMTG Gap-Bed Lather Machine
Brand: DMTG
SKU: 141435306
Availability: InStock

CDS6266C DMTG Gap-Bed Lather Machine thumbnail-1

CDS6266C DMTG Gap-Bed Lather Machine photo-1

US$ 9,500 - 12,000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Dalian Mach Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian Port China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Automatic

Max. Swing Diameter 660mm

Place of Origin Shandong, China

Brand Name DMTG

Model Number CDS6266C

Voltage 380V

Power(W) 11KW

Dimension(L*W*H) 4780x1120x1800mm

Weight 4250kgs

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

CDS6266C DMTG Gap-Bed Lather Machine

Technical Data:

Item		CDS6240/50/56/66/76B		CDS6240/50/56/66/76C
Max. swing over bed		400/500/560/660/760mm
Max. swing over carriage		230/290/350/440/540mm
Max. swing over gap		700/760/780/870/965mm
Width of gap		250mm
Max. length of work piece		1000/1500/2000/3000mm
Width of guide way		394mm
Spindle nose		D8
Spindle speed		26~2000rpm (16 steps)	23~1800rpm CDS6276B only	26~1700rpm (16steps)	23~1530rpm CDS6276C only
Dia. of spindle bore		82mm		105mm
Taper of spindle bore		90/1:20		110/1:20
Longitudinal feed		0.044-1.48mm/rev
Cross feed		0.022-0.74mm/rev
Metric thread		0.35-80mm(53 or 77)
Inch thread		7/16-80tpi(47)
Module thread		0.2-40mm(45 or 66)
Diametrical pitch thread		7/8-160 DP (42)
Max. travel of cross slide		348/348/348/355/355mm
Travel of top slide		150mm
Travel of tailstock quill		150mm
Diameter of tailstock quill		75mm
Taper bore of tailstock quill		M5
Main motor power		10HP(7.5kW)/15HP(11kW.OPTIONAL)
Packing & Weight	1000mm	Wooden case(mm):2850×1150×1900 Metal pallet(mm):2780×1120×1800
		N.M.(kgs):2100/2150/2200G.W.(kgs):2670/2810/2860
	1500mm	Wooden case(mm):3350×1150×1900 Metal pallet(mm):3280×1120×1800
		N.M.(kgs):2150/2200/2250 G.W.(kgs):2950/3000/3050
	2000mm	Wooden case(mm):3850×1150×1900 Metal pallet(mm):3780×1120×1800
		N.M.(kgs):2260/2310/2360/2600 G.W.(kgs):3170/3220/3270/3800
	3000mm	Wooden case(mm):4850×1150×1900 Metal pallet(mm):4780×1120×1800
		N.M.(kgs):3030/3080/3150/2800 G.W.(kgs):4010/4060/4110/4250

About our company:

Founded in 1948. Our factory already entered the TOP 8 machine tool builders in the world. truly a leader in the machine tool industry worldwide. Our machines sell to more than 100 countries and regions worldwide

....
