Light weight concrete manual brick making machine for CLC plant
- 100 Set / Sets per Month
- Shanghai or as your requirement
- T/T L/C D/P D/A Credit Card PayPal
- China pe200x300 smallest jaw crusher
- Popular compound pendulum jaw crusher price
- 2016 china products stone coated steel roofing tile ,shingle steel roof tile
- 2016 china products lightweight roof tile,blue glazed roof tile
- colored metal roofing prices,sand coated metal roofing tiles
- roofing tiles coated with stones,roofing tiles for houses
Product Details
Condition: | New | Type: | Other, foam concrete block making machine | Brick Raw Material: | Other, lightweight concrete |
Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
Capacity: | 30m3/h | Place of Origin: | Henan, China | Brand Name: | GEC |
Model Number: | GM2000&GP30 | Voltage: | 380V or as your requirements | Power: | 22.75kw |
Dimension(L*W*H): | 2600*2250*3000mm | Certification: | ISO9001&CE | Warranty: | 1year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Light weight concrete manual brick making machine for CLC plant
New building material foam concrete block features:
*Low Cost *Light Weight
*Heat Preservation *Sound Insulation
*Fireproofing *Aseismatic
*High Construction Speed *Environmental Protection
GAODE Lightweight Concrete Brick Making Machine
1. Foam Concrete Mixer
2. Foam Concrete Pump
3. Foam Concrete Block Mould
4. Foam Concrete Block Cutting Machine
5. Foaming Machine
6. Foaming Agent
7. Foam Concrete Hardener
GM2000 foam concrete machine :
The foam concrete mixer mainly includes mixer, feeder hopper, foam generator, water pump, control panel, tank.
Features:
1. The foam blending fast, blowing foam uniformly.
2. Without suspended matter, without the declining, it’s good for steady pouring.
3. Little loss ratio of foam maintain the foam proportion in the foam concrete to make the products with stability density.
4. No dead angle design, mixing the material toughly, storage in its bottom is less than 10mm, no material left on the four walls internal the mixing drum.
5. It could mixing variable materials, such as cement, fly ash, sand pulp, sand stone, perlite, and slag etc.
6. Variable speed mixing and internal structure alteration make its installation easy and mixing frequency high, it saves energy.
Technolog data :
Model | GM2000 |
Production Capacity | 15-20 m3/h |
Output Volume | 1500 L |
Material Input Volume | 2000 L |
Main Shaft Revolution | 32 r/min |
Hopper Lifting speed | 22 m/min |
Mixing Motor | 11 kW |
Winding Motor | 5.5 kW |
Water Pump Motor | 1.1 kW |
Vibrating Motor | 0.55 kW |
Foaming System | 5.5 kW |
Max. Moving Speed | 15 km/h |
Total Weight | 3200 kg |
Overall Dimension | 2600x2250x3000 mm |
GP30 foam concrete pump
Technolog data :
Model | GP30 |
Max.Output | 30 m^3/h |
Max.Conveying Pressure | 8Mpa |
Max.Horizontal Transporting Range | 600m |
Max.Vertical Transporting Height | 200m |
Max.Partice Size of Aggregates | 8mm |
Cylinder Bore | 80mm |
Delivery Cylinder Bore | 140mm |
Max.Pressure of Hydraulic System | 24Mpa |
Oil Pressure Box Volume | 200L |
Motor Power | 30kw |
Total Weight | 2200kg |
Overall Dimension | 3100*920*1300mm |
Dimension(mm) | 3900*1350*1450 |
Overall weight(kg) | 1950 |
GW30B wire cutting machine:
It is specially used to cut various foam concrete blocks. Easy operation, high efficiency. The block size between 100-200-300-400-500-600-700-800-900-1000-1100-1200mm could be adjusted willfully.
Technology data:
Name | GW 30B Wire Cutting Machine | ||
Electric Motor (Kw) | 2.2 kw*1 set, 0-56r/min adjusted 750w*2 set, 0-560r/min adjusted | ||
Effective hoisting height | 700mm | ||
| 1240*1240*225mm | ||
Net cutting size (L*W*H) | 1200*1200*600mm | ||
Cutting cycle | 60-180seconds | ||
Overall dimension (L*W*H) | 2160*2060*2280mm | ||
Total weight | 1100kg |
Features:
1.Could cut a block in two directions simultaneously at one time (cutting machine made by blade can cut only one direction and buyer must use two machines to cut one block in two times)
2. Cutting one block need 3-4 minutes, so max cutting capacity could up to 17 m3/hour
Foaming agent
The foaming agent is a high-tech product, it has the characteristics as high expansion ratio,
balanced density, foaming stability, and a long continuance, etc. Thus it is an environmental protective mighty foaming agent, which is nuisance-free and pollution-free.
Worksite of Manual Brick Making Machine:
Other application:
Delivery of Manual Brick Making Machine :
Our Manufactor shop:
Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.
We are a member of trade assurance on Alibaba, and our trade assurance amount is USD76000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
Q: What's the main differences between CLC Block and AAC Block?
A: The main difference is that CLC products belongs to Physical response, AAC products belongs to Chemical response.
Q: What kinds of raw materials could be used?
A: For making CLC bricks/blocks, the materials are mainly cement, fly-ash/sand/stone powder(as option), foam agent, water and Polypropylene fiber, etc.
Q: What's the material ratio for the foam concrete blocks?
A: Cement dosage no less than 30% at least, Sand/Fly-ash/Stone powder dosage no more than 70% at least, Foaming agent dosage 0.5~1.2liter normally.
Q: Can i use Ceramisites?
A: Yes, you can. Ceramisites could be also as the raw materials, and it could enhance the compressive strength of the wall.
Q: I am new on CLC machines, i don't know how to make it.
A: If necessary, we would dispatch engineers to you for technical collaboration.
Q: How to guarantee the machine works well before shipping?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
Q: Warranty period?
A:The warranty will be one year from the date of shipment. Any detected parts during
this period caused by the quality of products will be replaced by seller free of cost (exclude vulnerable parts and the breakdown caused by improper operation and other man-made reasons). Of course, if you need spare parts over the warranty period, please keep free to contact with us and we are always here offer service in 24hours every day.
