SPT Series Tractor Mounted Deep Water Well Drilling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GD100 Portable Electric DTH Portable Drilling RigUS$ 1,000 - 3,000MOQ: 1 Set -
Rotating-Jet Strengthening Foundation Pile Geological Drilling Rig For SaleUS$ 20,000 - 38,000MOQ: 1 Set
-
Hydraulic Truck Mounted Water Well Drilling Machine With CE ISOUS$ 68,000 - 80,000MOQ: 1 Set
-
Professional Manufacture 200m Trailer Used Water Well Drilling Machine for SaleUS$ 20,000 - 100,000MOQ: 1 Set
-
Diesel Engine 300m Depth Trailer Mounted Water Well Drilling RigUS$ 10,000 - 100,000MOQ: 1 Set
Condition
New
Type
Rotary Drilling Rig
Power Type
Diesel
Place of Origin
Henan, China
Brand Name
GEC
Model Number
SPT series deep well drilling machine
Usage
Water Well
Voltage
diesel engine
Power(W)
80kw
Dimension(L*W*H)
15.2*2.5*3.6m
Weight
12ton
Certification
CE
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
SPT series truck mounted deep well drilling machine
Product Description
Application:
1.drilling for hydrogeology exploration and foundation pile hole of engineering construction.
2.it can drill soil,gravel layer and bedrock.
Feature:
1SPT series is a truck mounted rotary water well drilling rig.
2.Mechanical drive,large through hole diameter of rotary table, large torque.
3.easy operation, compact structure, complete accessories.
Specification:
| Basic Parameter | ||||
| Model | SPT400 | SPT600 | SPT1000 | SPT1500 |
| Through hole diameter of rotary table | 530mm | 650mm | 650mm | 660mm |
| Drilling depth | 400m | 600m | 1000m | 1500m |
| Slewing speed of rotary table |
forward&reverse: 140,77,44r/min |
forward&reverse: 160,89,41,23r/min |
forward&reverse: 153,89,55,39r/min |
|
| Max.torque of rotary table | 16KN.m | 25KN.m | 25KN.m | 25KN.m |
| main winch single rope pull | 30KN | 50KN | 70KN | 80KN |
| Diesel engine | 100HP | 150HP | 260HP | 350HP |
| Electric motor | 75kw | 110kw | 200kw | 250kw |
| Drill tower effective height | 15.2m | 15.3m | 16m | 16m |
| Dimension | 15.2*2.5*3.6m | 15.3*2.62*3.66m | 16.3*2.62*3.66m | |
| Total weight | 12ton | 15ton | 22ton | 26ton |
