Automatic Bottle Blowing Machine
Machine Features--- pet bottle blowing machine
1 Fully Automatic Molding Machine perform input and ready bottle output system.
2.The Fully Automatic Molding Machine adopts overall structure of super-standard anti-vibration design, high-speed operation state of the machine will shake down to a minimum.
3. Fully Automatic Molding Machine adopts modular assembly method, greatly decrease the local amendments due to technological improvements when the machine is on processing.
4 The structure of Fully Automatic Molding Machine oven adopt the international most advanced energy-saving technology of infrared radiation heating, temperature control with automatic negative feedback, closed-loop regulation model. Fully Automatic Molding Machine
5 Automation controlling item adopts international high-end computer system, heating, collecting and measuring perform temperature with simulation input and output module.
6 Man-machine interface displays current production situation, available for on line switching, parameter modification and production accounting, with automatic alarm, automatic fault detection and diagnose. Fully Automatic Molding Machine
7 Storing more than 7 kinds specification for making bottle.
8 Adopt latest international air pneumatic. Fully Automatic Molding Machine
9 In order to save air, we choose high pressure blowing exhaust recovery system, which can save energy by 10-15%.
Technical Details--- pet bottle blowing machine
Model |
ZG-500 |
ZG-2000 |
ZG-4000 |
ZG-6000 |
Clamping force |
150KN |
180KN |
370KN |
565KN |
Clamping stroke |
120-175MM |
120-175MM |
120-175MM |
80-130MM |
Number of cavities |
1Cavity |
2Cavity |
4Cavity |
6Cavity |
Theoretical output |
1000BPH |
2000BPH |
4000BPH |
5500BPH |
Max.mould thickness |
250MM |
250MM |
250MM |
300MM |
Total power |
20KW |
28KW |
50KW |
70KW |
ntainer volume |
6L |
1.5L |
1.5L |
1.5L |
Neck diameter range |
16-38mm |
16-38mm |
16-38mm |
16-38mm |
ntainer diameter |
110mm |
110mm |
110mm |
110mm |
ntainer height |
380mm |
380mm |
380mm |
360mm |
Photos Show--- pet bottle blowing machine
