Help CenterElectrical Plastic Injection Moulding Machine
Related Products
This unit of our pet preform injection machine composed of imported advanced hydraulic components. System pressure is controlled by proportional valve. According to users demand, a quick mold clamping device and fast-respond excellent control valves also can be fitted on the unit.
CLAMPING
1. FEA designed double-toogle five-joint clamping machinery
2. High rigidity mould platen with enlarged space between tie bar, fit for larger scope of the moulds
3. Large moving die stroke with smooth & fast motion
4. Electrical & mechanical safety protection device
5. Automatic centralized lubrication system
6. Gear regulating the mould driven by oil motor
INJECTION UNIT
-Twin cylinder balanced injection system
-High torque oil motor directly drives screw to complete the pre-injection
-Specific screw and barrel designs are available for processing different material requirements to ensure the production quality
-Multiple-stage control for pressure, speed, position to inject, keep pressure, charge material.
CONTROL UNIT
-It utilizes the plastic injection moulding machine special-purpose computer with rapid response, interactive interface
-Regulate barrel temperature deviation automatically
-Multiple-unit plastic moulding data memory system
-Main electric components with world famous brand ensuring safety performance of electric devices
-It real-timely monitors various actions and gives automatic warning for its defects.
-Clamp, injection, ejection action can choose linear displacement sensor for its control.
HYDRAULIC UNIT
-Main hydraulic components with world famous brand, ensuring stable quality of the machine.
-Low noise & rapid response oil pump system
-Adopt the cooling water flow distributor, controlling the cooling temperature easily.
Technology Parameter:
| ZS3580 | A | B | C | ||
| Injection Unit |
Screw Diameter | mm | 60 | 65 | 70 |
| Screw L/D Ratio | L/D | 22.8 | 21 | 19.5 | |
| Cylinder head Volume | cm3 | 814 | 955 | 1108 | |
| Shot Weight | g | 740 | 869 | 1008 | |
| Plastic Rate(PS) | g/s | 38 | 52 | 62 | |
| Injection Rate(PS) | g/s | 245 | 288 | 334 | |
| Injection Pressure | Mpa | 198 | 169 | 145 | |
| Clamping Unit |
Clamping Force | KN | 3580 | ||
| Max mould Opening Stroke | mm | 660 | |||
| Mould Thickness(Min-Max) | mm | 250-700 | |||
| Distance Between Tie-Bars | mm | 660×660 | |||
| Ejection Force | KN | 62 | |||
| Ejector Stroke | mm | 160 | |||
| Others | Pump Motor Power | KW | 30 | ||
| Heating capacity of screw cylinder | KW | 16.55 | |||
| Oil tank capacity | L | 655 | |||
| Rated Pressure of Oil pump | Mpa | 16 | |||
| Machine Dimensions (L*W*H) | m | 6.85×1.75×2.24 | |||
| Machine Weight | T | 11.4 | |||
| Mould Orientation Ring Diameter | mm | Φ160H7 | |||
| Sphere Diameter of Nozzle | mm | SR15 | |||
Product show
