Extrusion Machine Pharmaceutical
EMP-45 plastic extrusion fully automatic blow moulding machine was specially designed for making plastic water bottles,medical bottles,oil bottles,plastic balls ,suction tubes and other small plastic containers not over 1.5L.
pharmaceutical bottle blow molding machine Products produced by our machine
The main components of the machine. ( LHB45D )
electronic parts |
|
Name | Trader |
Micro computer control system | Japanese MITSUBISHI |
Temperature Controller | TAIWAN HONGGE PID |
Auxiliary Relay | OMRON |
contactor | Schneider from France |
Electric motor | Three phase 220V or 380V |
Power Source | TAIWAN MEANWELL |
Transducer | CHINSC Japan |
hydraulic parts |
|
Name | Trader |
Oil pump | TAIWAN HIGH-TECH |
Valve | AIRTAC/TAIWAN |
Oil pump and connection | TAIWAN |
Sealed part | HALLITE |
air control system |
|
Name | Trader |
Cylinder | AIRTAC |
Air Valve | AIRTAC |
Technical Parameters: ( LHB45D )
Max. Product volume | 1.5L |
Out put capacity | 500~600pcs/h |
Screw diameter | 45mm |
Screw L/D ratio | 24:1 L/D |
Screw drive power | 10 KW |
Screw heating capacity | 2.6 KW |
No.of heating zone | 3 zones |
Output of HDPE | 35 KG/H |
Oil pump drive power | 4.8 KW |
Clamping force | 32KN |
Max.size of mold | 80-350mm |
Mold stroke | 250 X 320mm |
Max.die diameter | 80mm |
Blowing pressure | 0.6 mpa |
Air Volume | 0.4M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 30 L/MIN |
Size of Machine | 2.6x1.4x2.2m |
Weight of machine | 2.8 ton |
Hope we could have more chances to discuss the more details about the machine you want.
Also you will be very welcomed to visit us at any time.
