Extrusion Machine For Polyethylene

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Bottle
Plastic Processed	PP	Blow Moulding Type	Extrusion Blow Moulding
Automatic	Yes	Place of Origin	Jiangsu, China
Brand Name	Mars	Model Number	EBP-60
Voltage	380V	Power(W)	17kw
Dimension(LWH)	3.01.72.5(m)	Weight	5.8T
Certification	CE	Warranty	1 Year
After-sales Service Provided	Engineers available to service machinery overseas

Extrusion Machine For Polyethylene

	Units	KAL60series
Material		PE.PP.PVC.PA....
Max container capacity	L	5
Number of die	set	1.2.3.4
Output(Dry Cycle)	Pc/hr	1100
Machine dimension(L×W×H)	M	3.0×1.7×2.5
Total weight	ton	5.8
Clamping unit
Clamping force	KN	65
Platen opening stroke	mm	164-524
Platen size	mm	320×380
Max mould size(W×H)	mm	380×390
Mould thickness	mm	153-300
Power
Max drive	KW	26
Total power	KW	32.5
Fan power for screw	KW	0.14×3
Air pressure	Mpa	0.6
Air consumption	m³/min	0.5
Average energy consumption	KW	17
Extruder unit
Screw diameter	mm	60
Screw L/D ratio	L/D	24
Plasticizing capacity	Kg/hr	70
Number of heating zone	zone	3
Extruder heating power	KW	6.5
Extruder driving power	KW	11
Die-head
Number of heating zone	Zone	3
Power of die heating	KW	2.5
Max die pin diameter	mm	140
Center distance of double die	mm	150/160
Center distance of tri-die	mm	110
Center distance of tetra-die	mm	80

Basic Equipment

Clamping system	Single translation+High-percision guide+Large arm cylinder axle
Extruder unit	Hard gear box+Inverter
Die system	Control-incoming die with special steel
Hydraulic system	Hydraulic valve,Seal parts and Proportional control
Control system	Import PLC+Human-machine+PLC automatic temperature control model

Technical characteristic :

PLC+touch screen, making the operation easy, automatic malfunction alarm with selfdiagnosis, making the malfunction clear at a glance.

Center input die head, eliminating the knit line completely and making it easy to change the material and color.

Double linear rolling motion guider in moving, opening and closing mold, making the clamping force equally distributed, so the cut is smoother.

Control the hydraulic system with imported proportional valve, ensuring The action steasy, accurate and energy saving.

High speed and efficient plasticizing system, mixing well and ensuring the produce purity.

Product show
