This Reactor is used to cook and react the chemical products, food, juice, jam etc. Its material is good stage stainless steel. Its capacity is 2200L. The capacity, size, shape and other details can be customized. It is with anchor support to make it work stable. It has three layers which are inner layer, jacketed kettle and insulation layer. The steam will be injected into the jacketed layer of the kettle to make the product heated evenly. It is with an agitator, condenser and vacuum pump.
Technical Parameter:
Name |
Vacuum Reactor |
Capacity (L) |
2200 |
Barrel Size (mm) |
1400×1220 |
Material |
SUS316L for contact part and SUS304 for other parts |
Work Pressure of the Inner Layer (Mpa) |
Normal Pressure |
Work Pressure of the Jacketed Layer (Mpa) |
0.2 |
Work Temperature of the Inner Layer (°C) |
Normal Temperature |
Work Temperature of the Jacketed Layer (°C) |
120 |
Agitate Type |
Scrapping Type |
Motor |
Motor Power: 5.5kw; vertical reduction gear (50r/m); single seal face cauldron-using mechanical sealing |
Top of the Reactor |
There are DN400 quick-open type manhole cover, cleaning ball orifice, material inlet and outlet orifice, sight light connect orifice, breather etc. All the contact part with the material is quick-install connect type |
Condenser |
10m2; material: SUS304 |
Vacuum Pump |
7.5kw |
Polish |
Inner Surface:≤0.6μm; Outer Surface≤0.8μm |
