Help CenterStainless Steel Reaction Kettle For Food Production Line
Related Products
Specifications
Reacting the chemical products and food, juice, jam etcMaterial: SUS304 and SUS316L
Mirror Polish, with condenser
It is the reaction kettle for substance,such as protein,fat,amino acid,peptide,sugar,etc
fermenting tank
it is the reaction kettle for substance,such as protein,fat,amino acid,peptide,sugar,etc
after thermal reaction under high-temperature to produce the sustances full of strong and instense fragrance of cooked meat.and iti s the equipment specially for producing the substance full of frangrance of cooked meat.it can be used as an autoclave or as a small preparation tank.
the equipment has its appropriative blender group,and is attached by a condenser for heating and flow recycling.
Technical Parameter:
Name |
Vacuum Reactor |
Capacity (L) |
2200 |
Barrel Size (mm) |
1400×1220 |
Material |
SUS316L for contact part and SUS304 for other parts |
Work Pressure of the Inner Layer (Mpa) |
Normal Pressure |
Work Pressure of the Jacketed Layer (Mpa) |
0.2 |
Work Temperature of the Inner Layer (°C) |
Normal Temperature |
Work Temperature of the Jacketed Layer (°C) |
120 |
Agitate Type |
Scrapping Type |
Motor |
Motor Power: 5.5kw; vertical reduction gear (50r/m); single seal face cauldron-using mechanical sealing |
Top of the Reactor |
There are DN400 quick-open type manhole cover, cleaning ball orifice, material inlet and outlet orifice, sight light connect orifice, breather etc. All the contact part with the material is quick-install connect type |
Condenser |
10m2; material: SUS304 |
Vacuum Pump |
7.5kw |
Polish |
Inner Surface:≤0.6μm; Outer Surface≤0.8μm
|
