Help CenterHigh Speed Stainless Steel Reaction Tank
Related Products
-
See Larger Image Reaction Kettle Fermenting TankUS$ 2,150 - 31,200MOQ: 1 Unit -
Stainless Steel Reaction KettleNegotiableMOQ: 1 Unit
-
Stainless Steel Reaction Kettle For Food Production LineNegotiableMOQ: 1 Unit
-
Hot Stianless Steel Reaction Tank SaleNegotiableMOQ: 1 Unit
-
HH Recator Tank SaleNegotiableMOQ: 1 Unit
Specifications
Reacting the chemical products and food, juice, jam etcMaterial: SUS304 and SUS316L
Mirror Polish, with condenser
Technical Parameter:
Name |
Vacuum Reactor |
Capacity (L) |
2200 |
Barrel Size (mm) |
1400×1220 |
Material |
SUS316L for contact part and SUS304 for other parts |
Work Pressure of the Inner Layer (Mpa) |
Normal Pressure |
Work Pressure of the Jacketed Layer (Mpa) |
0.2 |
Work Temperature of the Inner Layer (°C) |
Normal Temperature |
Work Temperature of the Jacketed Layer (°C) |
120 |
Agitate Type |
Scrapping Type |
Motor |
Motor Power: 5.5kw; vertical reduction gear (50r/m); single seal face cauldron-using mechanical sealing |
Top of the Reactor |
There are DN400 quick-open type manhole cover, cleaning ball orifice, material inlet and outlet orifice, sight light connect orifice, breather etc. All the contact part with the material is quick-install connect type |
Condenser |
10m2; material: SUS304 |
Vacuum Pump |
7.5kw |
Polish |
Inner Surface:≤0.6μm; Outer Surface≤0.8μm |
