Name	Vacuum Reactor
Capacity (L)	2200
Barrel Size (mm)	1400×1220
Material	SUS316L for contact part and SUS304 for other parts
Work Pressure of the Inner Layer (Mpa)	Normal Pressure
Work Pressure of the Jacketed Layer (Mpa)	0.2
Work Temperature of the Inner Layer (°C)	Normal Temperature
Work Temperature of the Jacketed Layer (°C)	120
Agitate Type	Scrapping Type
Motor	Motor Power: 5.5kw; vertical reduction gear (50r/m); single seal face cauldron-using mechanical sealing
Top of the Reactor	There are DN400 quick-open type manhole cover, cleaning ball orifice, material inlet and outlet orifice, sight light connect orifice, breather etc. All the contact part with the material is quick-install connect type
Condenser	10m2; material: SUS304
Vacuum Pump	7.5kw
Polish	Inner Surface:≤0.6μm; Outer Surface≤0.8μm
