        hengchuanCylinder Washing Machine

Shandong Hengchuan Ore Machinery Co.,Ltd

Company profile

   Shandong Hengchuan   Ore Machinery Co. , Ltd, established in 2002, is leading ore machinery in china. Company covers area of 20000 square meters.

   Our main products :Placer Gold Mining Machine ,Magnetic Separator ,Sand Mining and Washing Machine, Mining Dredgers ,Sand Barges, Particular Vessels, etc. They have been sold not in domestic market, but export to more than thirty foreign countries, like Philippines, Malaysia, North Korea   , Mongolia, Cameroon, South Africa, Ghana, Brazil, etc.

Shandong Hengchuan Ore Machinery Co.,Ltd

 Short Introduction

  1Apply to old river way, old rive bed, alluvial mine.

 2Require have no  clay  in the ore and not wet.

 3It is designed for  clay ore with obvious effect, can equip magnetic  separator.

 4The average recovery rate is about 90%.Enrichment ratio is about  1000:1

 5 The machine is kind of automatic machine.





The working principle of:

Cleaning the barrel is four tug support, the motor drives the gear reducer, gear drives the cleaning barrel size low speed rotation.Containing mud pie and powder ore feeding fed, the rotating drum, waswashing wear-resisting rubber lining the inside of the drum installed in a certain angle with dropping continuously, from feeding end to a discharge end mobile process repeatedly, and was normal or reverse flushing water flushing washing polyester, clean ore by lifter lifting unloading the doubleconical sieve, into coarse, fine, in three particle grade respectively discharge. Wastewater containing sludge through the discharge or to theoutflow of the feed end of the baffle plate with a hole.



  Shandong Hengchuan Ore Machinery Co.,Ltd

To improve the efficiency of measures                                    (1)The improvement on the cylindrical ore washing machine lining board

In order to extend the minerals in the ore washing time pulping section,friction effect between the enhancement of ores and the lining board,through research and experiment, the wet formula design by using a unique Yantai Xinhai wear rubber industry, nano composite dispersion technology, wear-resistant rubber obtained has excellent wear resistance, strength and elasticity, long service life, adopting the rubberwave type lining plate instead of smooth cambered surface lining plate,and the relief and roughness in new lining board increase. Drum washerusing wear-resisting rubber lining plate, prolonging the effective time of ore in the drum washer pulping, the ore got soaked, scrub fully, improvewashing efficiency, at the same time, because the lining board wear resistance increased, prolonged service life, reduce the cost of.

(2)Heightening the drum washer ore end retainer height

The cylindrical ore washing machine in the treatment of mud containing rate high, mud plastic index of the refractory ore, lump ore mud to gluethe broken effect is not strong, mud removal effect of lump ore sieve the poor. In order to effectively extend the lump ore ore washing time, make the lump ore fully scrub, the drum washer sieve sublevel ore ringheightened, so, prolong the lump ore in ore washing cylinder washing is effective in improving the time machine, mud removal effect of lump ore.

 (3) Change the cylindrical ore washing machine speed

Cylindrical ore washing machine speed is reduced, there is a greater negative impact on the ore washing process under the effect of launder washer, with the ore feeding quantity increases, the next process tankwasher product mud containing rate increase. The main reason is because the cylindrical ore washing machine speed is reduced, the orelift, scrubbing effect is reduced, fine ore into the drum washer sievepiecewise from between the screen bars falling into the next process tankwashing machine, greatly reduces the fine ore in the cylinder wash scrubtime mill, the surface is clay tightly wrapped, seriously the influence of thewashing effect.

  Shandong Hengchuan Ore Machinery Co.,Ltd

installation and commissioning:

1, the equipment should be installed in the level of concrete foundation,fixed with anchor bolts.

2, the installation should pay attention to the host body and the horizontalvertical.

3, after installation, check all parts bolt looseness and mainframe warehouse door is fastened, please fasten.

4, according to the dynamic allocation of power line equipment andcontrol switch.

5, check, empty load test, commissioning normal production can be carried out.

  Shandong Hengchuan Ore Machinery Co.,Ltd

Machine maintenance:

1, responsible for all load bearing of the machine, so the good lubricationis strongly related to the service life of the bearing, it directly affects theservice life of the machine and the operation rate, thus requiringinto thelubricating oilmust be clean, the seal must be in good condition, mainoiling the machine at (1) rotating bearing roller bearing ((2) 3) all the gear(4) movable bearing, sliding plane.

2, the installation of the new tyre prone to loosening often must bechecked.

3, pay attention to all parts of the machine is working.

4, pay attention to check the degree of wear parts easy to wear, always pay attention to the replacement of worn parts.

Chassis plane 5, active device, dust and other materials should be out to avoid machine encounter not broken material activities bearing can not move on the chassis, so that the occurrence of serious accidents.

Increased 6, oil temperature, should stop and check the reason to be eliminated.

7, the rotation of the gear in operation if the impact of noise should stop immediately check, and eliminate

  Shandong Hengchuan Ore Machinery Co.,Ltd

main technical parameters
