Hot Sale! 70t Multifuctional Pipelayer

Name: Hot Sale! 70t Multifuctional Pipelayer
Brand: Daifeng
SKU: 141325698
Availability: InStock

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

US$ 119,000 - 199,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Type:

Other, pipelayers

Place of Origin:

Shandong, China

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, pipelayers

Place of Origin Shandong, China

Brand Name Daifeng

Model Number DGY70

Power(W) 239kw

Dimension(L*W*H) 5.3*3.42*3.30mm(without boom)

Weight 55t

Warranty 12 months

Specifications

Maximum lifting weight: 70t
Rated power: 239kw
Excellent quality & competitive price

DGY70 MULTIFUNCTION PIPELAYER

TECHNICAL SPECIFICATION:

MAX. LIFTING CAPACITY (T)		70
MAX. LIFTING MOMENT AT Min. RANGE OF THE BOOM (KN.M)		836 (686kN×1.22m)
MAX. LIFTING MOMENT AT MAX. RANGE OF THE BOOM (KN.M)		784(156.8kN×4.50m)
MAX. LIFTING HEIGHT OF THE HOOK (M)		5.2
BOOM LENGTH (M)		7.0
HOISTING SPEED (EIGHT TIMES) (M/MIN)		6
TIME OF CHANGE RANGES (S)		60
MODEL OF CHASSIS		PD320Y
MODEL OF DIESEL ENGINE		CUMMINS NTA855—C360
RATED POWER (KW/RPM)		239/2000
TRACK GAUGE (MM)		2380
LENGTH OF TRACK ON GROUND (MM)		3620
TRACK SHOE WIDTH (MM)		760
MODEL OF HYDRAULIC PUMP		CBGj3100/3100/1040
RATED WORKING PRESSURE OF SYSTEM (MPA)		21
LIFTING WINCH		HYDRAULIC DRIVEN, PLANETARY TRANSMISSION, FREE-FALL FUNCTION
RATED PULLING FORCE OF SINGLE ROPE (N) (THIRD LAYER)		100,000
DIAMETER OF WIRE ROPE (MM)		d22
RANGING WINCH		HYDRAULIC DRIVEN, PLANETARY TRANSMISSION
RATED PULLING FORCE OF SINGLE ROPE (N) (SECOND LAYER)		100,000
DIAMETER OF WIRE ROPE (MM)		d18
TEMPERATURE OF SURROUNDINGS (°C)		-20~+40
OVERALL DIMENSION (LWH)	WITH BOOM (M)	5.3×4.88×7.85
	WITHOUT BOOM (M)	5.3×3.42×3.30
OPERATING WEIGHT (T)		55
