Pipelayer 25t SP25Y1.Good quality, low price.
2.World famous brand,and professional service
3.Max.lifting capacity:25t.
Pipelayer 25t SP25Y
The SP25Y pipe layer is equipped with advanced international technology to provide load feedback and prevent overloading while working on pipe laying projects. With a hydraulic pilot control system, the operations of working devices such as the hook and lifting arm are integrated into a single lever, which is capable of precise, sensitive performance. The machine has been designed to specially measure operating functions in order to prevent overturning or rolling over.
Type | SP25Y |
Engine Model | Steyr WD615T1 |
Rated power & revolution (kw/rpm) | 120/1850 |
Max.lifting weight(t) | 25 |
Operating weight(kg) | 22000 |
L x W xH(mm) | 4135*3050*3014 |
Min.turning radius(mm) | 2950 |
Track gauge (mm) | 2050 |
Ground length(mm) | 2635 |
Track shoes width(mm) | 560(660) |
Ground Pressure(Mpa) | 0.07(560mm) 0.06(660mm) |
Mas.lifting height(mm) | 4400 |
Boom swing amplitude (m) | 1.2-5.0m(5.5m boom) 1.2-5.6m(6.1m boom) |
Hook speed (m/min) | 0-12.0 |
Boom length(m) | 5.5(6.1) |
