Pipelayer 45t SP45Y1.Good quality, low price.
2.World famous brand,and professional service
3.Max.lifting capacity:45t.
Pipelayer 45t SP45Y
The SP45Y pipe layer is equipped with advanced international technology to provide load feedback and prevent overloading while working on pipe laying projects. With a hydraulic pilot control system, the operations of working devices such as the hook and lifting arm are integrated into a single lever, which is capable of precise, sensitive performance. The machine has been designed to specially measure operating functions in order to prevent overturning or rolling over.
Type | SP45Y |
Engine Model | Cummins NTA855-C280 |
Rated power & revolution (kw/rpm) | 169/2000 |
Max.lifting weight(t) | 45 |
Operating weight(kg) | 33000 |
L x W xH(mm) | 4750*3700*2360 |
Min.turning radius(mm) | 3200 |
Track gauge (mm) | 2250 |
Ground length(mm) | 3050 |
Track shoes width(mm) | 610(780) |
Ground Pressure(Mpa) | 0.086(0.070) |
Mas.lifting height(mm) | 5250 7210(7500) |
Boom swing amplitude (m) | 1.2-6.65 |
Hook speed (m/min) | 0-6.0 |
Boom length(m) | 6.5(7.5) |
