15t Multifuctional Pipelayer

15t Multifuctional Pipelayer thumbnail-1
15t Multifuctional Pipelayer photo-1
US$ 29,000 - 39,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Pipe Material:
Stainless Steel
Place of Origin:
Shandong, China
Brand Name:
Daifeng
Contact Supplier Request Quote Chat Now
Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Pipe Material Stainless Steel
Place of Origin Shandong, China
Brand Name Daifeng
Model Number DGY15-D
Power(W) 88.2kw
Dimension(L*W*H) 5.528*4.30*6.18
Weight 22.47t

Specifications

1. Maximum lifting weight: 15t
2. Rated power: 88.2kw
3. Excellent quality & competitive price

DGY15-D MULTIFUNCTION PIPELAYER

TECHNICAL SPECIFICATION:



 Max. lifting capacity (t)   15
  Lifting capacity with Sub. boom(t)   3.0
  Max lifting monment at Min. Range of boom(kN.m)   179(147kN×1.22m)
  Max lifting monment at Max. Range of boom(kN.m)   126(28kN×4.50m)
  Max. lifting height of hook of main boom(m)   3.96
  Max. lifting height of hook with Sub. boom(m)   6.9
  Length of main boom(m)   5.49
  Length of Sub. boom(m)   3
  Working Range with Sub. boom   3.0~5.5
  Lifting speed(6times)(m/min)   10
  Time of change range(1.22-4.5m)(s)   5.4
  Sub. boom's retraction (mm)     Lifting   15
 Falling   15
  Model of chassis   PD120
  Model of engine   6135K-2a
  Operating weight(t)   22.47
  Overall Dimension(L×W×H)  With main boom(m)   5.528×4.30×6.18
 Without main boom(m)   5.528×3.05×3.01
 With Sub. boom(m)   5.528×5.56×8.80
  Min. turning radius (m)   6.8
  Temerature of surroudning(°C)   -20~+40
  Model of alternator   UCI224G24
  Rated output of generator(kW)   68
  Model of Arc welding machine (Recommended) Panasonic YM—350RF2
Lincoln DC-400
  Number of welding machine   2
  Model of compressor   W-0.6/20
  Displacement(m3/min)   0.6
  Pressure of output (Mpa)   2
  Rated power of compressor(kW)   7.5
