Centrifugal Concentrator for Gold Separtor

Centrifugal Concentrator for Gold Separtor photo-1
Centrifugal Concentrator for Gold Separtor photo-2
Centrifugal Concentrator for Gold Separtor photo-3
Centrifugal Concentrator for Gold Separtor photo-4
Centrifugal Concentrator for Gold Separtor photo-5
US$ 2,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Gravity Separator
Production Capacity:
8-80t/h
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Gravity Separator
Production Capacity 8-80t/h
Brand Name KD
Model Number KDSTL
Voltage 280V or 360V
Power(W) 4-15kw
Dimension(L*W*H) 1150*1360*1250
Weight 4-11t
Certification ISO9001
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Centrifugal Concentrator  for Gold Separtor

Product Description

 Parameter

Model

STL19

STL30

STL60

STL80

STL100

Capapcity T/H

0.25-0.30

3-5

15-20

40-50

80-100

Feed particles mm

0-3

0-4

0-6

0-6

0-6

Feed density %

0-50%

0-50%

0-50%

0-50%

0-50%

Recoil of water T/H

1.5-2

4-6

10-15

17-25

40-60

Concentrate production

 (kg per time)

2-3

10-20

30-40

60-70

70-80

Motor Power kw

0.75

3

7.5

11

18.5

Cone rotational speed

800

600

460

400

360

Water Pressure MPa

0.04

0.1

0.16

0.18

0.2

Overall Size mm

790×785×790

1150×1360×1250

1970×1670×1750

2300×1800×2200

2500×2000×2400

Weight

300kg

500kg

1300kg

1800kg

2800

Details about the product:

Centrifugal Concentrator for Gold Separtor

Centrifugal Concentrator for Gold Separtor

Centrifugal Concentrator for Gold Separtor

Centrifugal Concentrator for Gold Separtor

Centrifugal Concentrator for Gold Separtor

Centrifugal Concentrator for Gold Separtor

Product in Gold Mining Procedure:

Company Information

Qingzhou Keda Mining Machine Co.,Ltd. specializein dredgers for various industries: Environmental, Sand Production and Mining Machine.

Our factory produces a variety of series products , such as : cutter suction dredger, bucket chain dredger, self- propelled dredger, gold panning dredger, iron extracting dredger, sand sieving machines, crusher, gold separator equipment line, and various kinds of machines for mining equipment.

We own the professional R&D department , CAD drawing design center , quality control department and Installation & Adjustment to After Service .

We can customize special dredging and mining equipment according to different environment and customer requirement which can accomplish the whole set of working procedures of filtering , extracting , separating, washing , classifying and put our qualified products directly. Our experienced engineers will work closely with you to customize a best dredging solution for your particular needs.

Now we have developed a dominant role in the dredge manufacturing industry and expand our market to many countries.

The best quality, excellent service, good credit, competitive price, the abundant strength, what made us confidence with your satisfaction.

Our Services

1)After sales technical support,machine installation,spare part service,anticipated training
for our customers are provided by our specialist engineers and technicians.
2)Our technical service department is ready to serve and reslove your questions via online support,phone calls or on-sit support.
3)We reckon service insight to increase the levels of challenge with our specialized technical staff.Genial customer relations,technical facilities for intact spare parts deliverised with
spare part labor warranty,affordable spare parts and on site service are just a few examples
of our professinal custoemer approach.
