Fine gold mineral separators centrifugal separator
1.Feature
a.Easy to move.
b.Easy to Control.
c.The purity of concentrate is high.
2.Basic Parameters
Model | STL19 | STL30 | STL60 | STL80 | STL100 |
Working Capapcity T/H | 0.25-0.30 | 3-5 | 15-20 | 40-50 | 80-120 |
Feed particles mm | 0-3 | 0-4 | 0-6 | 0-6 | 0-6 |
Feed density % | 0-50% | 0-50% | 0-50% | 0-50% | 0-50% |
Recoil of water T/H | 1.5-2 | 4-6 | 10-15 | 17-25 | 40-60 |
Concentrate production (kg per time) | 2-3 | 10-20 | 30-40 | 60-70 | 70-80 |
Motor Power kw | 0.75 | 3 | 7.5 | 11 | 18.5 |
Cone rotational speed | 800 | 600 | 460 | 400 | 360 |
Water Pressure MPa | 0.04 | 0.1 | 0.16 | 0.18 | 0.2 |
Dimensions mm | 790×785×790 | 1150×1360×1250 | 1970×1670×1750 | 2300×1800×2200 | 2500×2000×2400 |
Weight kg | 300 | 500 | 1300 | 1800 | 2800 |
3.Product Show
KDTJ type gold centrifugal separator equipment is a kind of centrifugal separation equipment, it is gold, sand monomer gold in the mine and a variety of other metal recycling.
Placer gold recovery rate can reach more than 95%. MaiJin monomer of gold in the grinding fineness is less than 0.074 mm (65%), monomer recovery rate of gold can reach more than 98%.
4.Working Process
The equipment by the electric motor(2), through the belt transmission (1) drive shaft (11), made the inner sleeve (5) at high speed. Pulp by the feed tube (4), give inner sleeve (5), pulp under the action of centrifugal force field, the sorting process intensification. Heavy mineral stay, (5) in the cell,light minerals by tailing discharge chute (7). After each class working, the concentrate willexpel from row ore mouth after downtime (10).
2.Within warranty period,we provide free repair if quality problems emerge.
3.Engerneers are avaliable to service oversea to assemble and test the machine according to the contract.
4.Free training of the first batch of operater proved, any question or problem about the products can be answered via online support, phone calls or on-sit support 24 hours.
5.Why choose us
1.We have our own plant and enginner ,we will design the gold wash equipment according to your situation and requirements.
2.We have rich experience in export,our customers from all over the word ,such as Ghana,Bengal and so on.
3. We have petent,we are alone in the China ,even in the world.
4.We have a great group,we will give you a most sincere service.
If you have any quuestion about our company or products, please feel free to contact with me, and i will try my best to make you satisfied.
Fergie Wu
Qingzhou Keda Mining Machine Co,.Ltd.
E-mail:sales08(at)
Skype:kedamachinery08
Tel/Fax:0086-536-2105419
Mob:0086-18353690657
Thanks for your browse!
