Semi-auto bitumens prayer LMT5162GLQ-DongFeng truck
Negotiable
/ Unit
1 Unit(Min.Order)
- 100 Piece / Pieces per Month
- SHANGHAI
- T/T
You May Like
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- High Configuration Computer Control 120T/H Mobile Concrete Hot Drum Mix Plant
- Stationary Building Machine Equipment 160T/H Asphalt mixing plant LB2000
Product Details
Condition: | New | Brand Name: | ZHETONG | Model Number: | LMT5162GLQ |
Certification: | CE | Warranty: | 14 MONTHS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Model | LMT5162GLQ | Engine Model | B19033-Cummins | |
Chassis Model | DFL1160BX | Displacement (L) | 5.88 | |
Truck Type | flat head 4×2 rear drive | Max. Power (kw/r/min) | 140/2500 | |
Dimension | 8995×2490×3200 | Max. Torque (N·m/r/min) | 611/1400-1600 | |
(L×W×H) mm | Burner Diesel Tank Capacity (L) | 90 | ||
Cab Passenger | 3 | Cleaning Diesel Tank Capacity (L) | 25 | |
Vehicle kerb Mass (kg) | 9105 | Fuel Tank Capacity (L) | 90 | |
Rated Load Mass (kg) | 5700 | Hydraulic Oil Tank Capacity (L) | 40 | |
Max. Total Mass (kg) | 16000 | Decelerator Model | Z165 | |
Distribution of Axle Load (KG) | Front Axle (no load) | 3405 | Decelerator Gear Ratio | 5.8116 |
Front Axle (full load) | 6000 | Gearbox Model | A13D | |
Rear Axle (no load) | 5700 | Asphalt Pump Model | QGB450 | |
Rear Axle (full load) | 10000 | Asphalt Pump Displacement (ml/r) | 1160 | |
Wheelbase (mm) | 5000 | Asphalt Pump Rotating Speed (r/m) | 100-460 | |
Tread (front/rear) mm | 1940/1860 | Power Take-off Model | DONGFENG AUTOMOBILE | |
Min. Ground Clearance (mm) | 248 | Burner Model | G20 | |
Suspension (front/rear) mm | 1245/2750 | Air Compressor Model | V-0.2/0.8 | |
Approach/Departure Angle (°) | 20/11 | Rated Atmospheric Pressure (Mpa) | 0.6 | |
Ramp Angle (°) | 23 | Hydraulic Pump Model | CBQ-F550 | |
Max. Speed (km/h) | 90 | Hydraulic Motor Model | L2F63W2P2 | |
Working Speed(km/h) | 2.5~10.5 | Rated Pressure (Mpa) | 20 | |
Max. Gradeability (%) | >23 | Asphalt Tank Capacity (L) | 10000 | |
Tyre Model | 9.00-20×16PR | Nozzle | 39 | |
Tyre Pressure front/rear (kPa) | 630/630 | Asphalt Spraybar Width (m) | 0~6 | |
Main Drive Ratio | 4.875 | Asphalt Spraybar Value (kg/m2) | 0.3~3.0 | |
Max. Braking Distance (m) | <10 | Emission Standard | Euro III | |
Min. Turning Circle Dia. (m) | <23.8 | |||
Oil Consumption (L/100km) | <20 | |||
Parking Gradient (%) | >20 |
