Metong 6T/H Productivity Asphalt Milling Machine/emulsion Bitumen Equipment

No.

Name

Specification

Remark

1

Max productivity

6m3/h

Asphalt contect60%,Water solution 40%

2

Basic bitumen transport gear pump

model

YCB-6

Heat conducting oil for temperature preservation; Frequency conversion speed; Honeywell sensor

flux

6 M3/h

Match engine

4Kw

3

Colloid milling

Model

S300.4W.0.5

Flux

10 M3/h

Match engine

43Kw

4

Water pump

Model

ISW 40-125(I)

Flux

12.5 M3/h

RPM

2900rpm

Match engine

1.5 Kw

5

Emulsifier supply pump and gear pump

Quantity

1

flow meter throttle valve is available

model

ISWH 40-125(I)

flux

12.5 M3/h

RPM

2900RPM

Match engine

1.5Kw

6

Emulsifier circulation pump

Quantity

1

Model

ISWH 40-125(I)

Flux

12.5 M3/h

RPM

2900RPM

Match engine

1.5Kw

7

Emulsifier mix tank

Quantity

2

Capacity

4M3/unit

Material

Stainless steel(#304) tank( corrosion prevention)

Tank dimension

tank chickness:3mm; top cover:5mm; inner diameter:1500mm;inner height:2400mm

thermal insulating layer thickness:50mm

Mixer

1.5Kw

80-15-Y-1.5-B12-270°,97rpm,190Nm

Decelerate

15

Derogate speed

97rpm

8

Finished emulsion bitumen transportation pump

Model

QGB/400/0.6

Flux

400L/min or  24 M3/h

Match engine

7.5 Kw

9

finished bitumen tank

Tank thickness

3mm

Capacity

2.5 M3

10

valves application

Emulsifier

DN50 ,dual clamp butterfly valve

Asphalt

Heat oil

manual operation ,High temperature  valve

water

ball valve in stainless steel

11

control system

Manual frequency control
