Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Paving Machinery > Semi-automatic Asphalt Distributor
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
METONG
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shanghai, China
Brand Name
METONG
Model Number
LMT5081GLQ
Certification
ISO
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
| SPECIFICATION OF LMT5081GLQ BITUMEN SPRAYER TRUCK | ||||
| (Semi-automatic Type) | ||||
| Model | LMT5081GLQ | Engine Model | CY4102-C3D | |
| Chassis Model | HFC1081KT | Displacement (L) | 3.856 | |
| Truck Type | flat head 4×2 rear drive | Max. Power (kw/r/min) | 80/2800 | |
| Dimension (L×W×H) mm | 7375X2010X2520 | Max. Torque (N·m/r/min) | 300/1400~1800 | |
| Cab Passenger | 3 | Cleaning Diesel Tank Capacity (L) | 35 | |
| Vehicle kerb Mass (kg) | 5200 | Fuel Tank Capacity (L) | 120 | |
| Rated Load Mass (kg) | 3095 | Hydraulic Oil Tank Capacity (L) | 100 | |
| Max. Total Mass (kg) | 8490 | Decelerator Model | Z16 | |
| Distribution of Axle Load (KG) | Front Axle (no load) | 1874 | Decelerator Gear Ratio | 5.8116 |
| Front Axle (full load) | 3396 | |||
| Rear Axle (no load) | 3086 | Asphalt Pump Model | QGB450 | |
| Rear Axle (full load) | 5094 | Asphalt Pump Displacement (ml/r) | 450 | |
| Wheelbase (mm) | 3815 | Asphalt Pump Rotating Speed (r/m) | 300~1200 | |
| Tread (front/rear) mm | 1665/1525 | |||
| Min. Ground Clearance (mm) | 176 | Burner Model | G20-474T1 ITALY RIELLO | |
| Suspension (front/rear) mm | 1085/2510 | Temperature Control Cabin | E5AZ JAPAN OMRAN | |
| Approach/Departure Angle (°) | 24°/12° | Inverter | NFA8212-2000W | |
| Ramp Angle (°) | 23° | Hydraulic Pump Model | CBQ-F540FPL | |
| Max. Speed (km/h) | 95 | Hydraulic Motor Model | LY-A2F63W2P2 | |
| Working Speed(km/h) | 1.5~10 | Rated Pressure (Mpa) | 15 | |
| Max. Gradeability (%) | >23 | Heat Conducting Oil Pump Model | GRY-40-25-160 | |
| Tyre Model | 7.50-16×12PR | Heat Conducting Oil Model | Great Wall 320# | |
| Tyre Pressure front/rear (kPa) | 680/650 | Control System | MT-5 (Simens) with flow display and can adjust the flow + rear plate control | |
| Main Drive Ratio | 5.571 | Asphalt Tank Capacity (L) | 5000 | |
| Max. Braking Distance (m) | <10 | Nozzle | 36 Copper (one cylinder controls three nozzles) | |
| Min. Turning Circle Dia. (m) | <15.5 | Spraybar Variable (m) | 0~5.5 | |
| Oil Consumption (L/100km) | <11.5 | Spraybar Value (kg/m2) | 0.3~3.0 | |
| Parking Gradient (%) | >20 | Emission Standard | GB17691-2005(Ⅲ) | |
| GB3847-2005 | ||||
