High efficiency dry ball mill (manufacturer)
- 40 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T
Product Details
| Condition: | New | Type: | Ball Mill | Motor Type: | Other |
| Power(W): | 15-800kw | Capacity(t/h): | 0.65-90 | Place of Origin: | Henan, China |
| Brand Name: | Yuhui | Model Number: | many types | Dimension(L*W*H): | different model |
| Weight: | 3.6-137t | Certification: | ISO9001:2008 | Warranty: | 12 months |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High efficiency dry ball mill (manufacturer)
Product Discription of ball mill:
Ball mill is a key equipment to grind the crushed materials, and it's widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics.
Working Principle of ball mill:
The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
Technical parameter of ball mill:
Model | Shell Rotation Speed(r/min) | Ball Load (t) | Feeding Size(mm) | Discharge Size(mm) | Capacity (t/h) | Motor Power (kw) | Weight (t) |
φ900×1800 | 38 | 1.5 | ≤20 | 0.075-0.89 | 0.65-2 | 18.5 | 3.6 |
φ900×3000 | 38 | 2.7 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 | 4.6 |
φ1200×2400 | 32 | 3.8 | ≤25 | 0.075-0.6 | 1.5-4.8 | 45 | 12.5 |
φ1200×3000 | 32 | 5 | ≤25 | 0.075-0.4 | 1.6-5 | 45 | 12.8 |
φ1200×4500 | 32 | 7 | ≤25 | 0.075-0.4 | 1.6-5.8 | 55 | 13.8 |
φ1500×3000 | 27 | 8 | ≤25 | 0.075-0.4 | 2-5 | 90 | 17 |
φ1500×4500 | 27 | 14 | ≤25 | 0.075-0.4 | 3-6 | 110 | 21 |
φ1500×5700 | 27 | 15 | ≤25 | 0.075-0.4 | 3.5-6 | 132 | 2407 |
φ1830×3000 | 24 | 11 | ≤25 | 0.075-0.4 | 4-10 | 180 | 28 |
φ1830×6400 | 24 | 23 | ≤25 | 0.075-0.4 | 6.5-15 | 210 | 34 |
φ1830×7000 | 24 | 25 | ≤25 | 0.075-0.4 | 7.5-17 | 245 | 36 |
φ2200×5500 | 21 | 30 | ≤25 | 0.075-0.4 | 10-22 | 370 | 48.5 |
φ2200×6500 | 21 | 30 | ≤25 | 0.075-0.4 | 14-26 | 280 | 52.8 |
φ2200×7500 | 21 | 33 | ≤25 | 0.075-0.4 | 16-29 | 380 | 56 |
φ2200×9500 | 21 | 38 | ≤25 | 0.075-0.4 | 18-35 | 475 | 62 |
