High efficiency grinding slag ore ball mill
1. Ore Ball Mill:
Ore ball mill changes the original grinding machine structure, its body and ground plank are an integral whole. So when fixing, it can be lowered onto a basic plane once only. Using biserial roller axletree with centripetal spherical support of the host axletree can reduce energy consumption by 30%.The original grille pattern forced discharging is substituted by the overfall pattern controlling one. This can improve the milled granularity and the capacity can be increased by 15-20%.
2. Ore Ball Mill Working Principle:
The ball crusher is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
3. Ore Ball Mill Main Technical Parameters:
Model | Feeding size(mm) | Discharging size(mm) | Weight of ball(t) | Rotational speed (r/min) | Power(kw) | Capacity(t/h) | Weight(t) |
Φ900*1800 | ≤20 | 0.075-0.89 | 1.4 | 42 | 18.5 | 0.65-2 | 3.6 |
Φ900*2100 | ≤15 | 0.075-0.83 | 1.7 | 41 | 15 | 0.7-3.5 | 3.9 |
Φ900*3000 | ≤20 | 0.075-0.89 | 2.5 | 41 | 22 | 1.1-3.5 | 4.5 |
Φ1200*2400 | ≤25 | 0.075-0.6 | 3.5 | 36 | 30 | 1.5-4.7 | 11.5 |
Φ1200*2800 | ≤25 | 0.075-0.6 | 4.5 | 36 | 37 | 1.5-5 | 13 |
Φ1200*4500 | ≤25 | 0.075-0.4 | 5.5 | 32 | 55 | 1.6-5.8 | 13.8 |
Φ1500*3000 | ≤25 | 0.047-0.4 | 8.68 | 31 | 75 | 2-7 | 17 |
Φ1500*3500 | ≤25 | 0.047-0.4 | 7.75-6.4 | 31 | 75 | 3-8.5 | 17.5 |
Φ1500*4500 | ≤25 | 0.047-0.4 | 10.5 | 27 | 110 | 3.5-8 | 21 |
Φ1500*5700 | ≤25 | 0.047-0.4 | 15 | 27 | 130 | 3.5-10 | 24.7 |
Φ1830*3000 | ≤25 | 0.047-0.4 | 18 | 26 | 160 | 4-12 | 28 |
Φ1800*3600 | ≤25 | 0.047-0.4 | 10.6-11.35 | 26 | 160 | 5-13 | 33.5 |
Φ1830*4500 | ≤25 | 0.047-0.6 | 12 | 26.5 | 185 | 5.5-20 | 35 |
Φ1830*7000 | ≤25 | 0.047-0.4 | 25 | 26 | 210 | 6.5-22 | 36 |
Φ2100*3600 | ≤25 | 0.047-0.4 | 14-15.2 | 24 | 185 | 15-30 | 46.8 |
Φ2200*5500 | ≤25 | 0.047-0.4 | 30 | 21 | 245 | 10-20 | 48.5 |
