Steel Rod Mill Hot Sell in 2011

Steel Rod Mill Hot Sell in 2011 thumbnail-1
Steel Rod Mill Hot Sell in 2011 photo-1
US$ 7,548 - 204,918 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Henan Yuhui Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Dalian Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Motor Type AC Motor
Power(W) different models
Capacity(t/h) 10t/bout
Place of Origin Henan, China
Brand Name Yuhui
Model Number different models
Dimension(L*W*H) different models
Weight different models
Certification ISO, BV
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

steel rod mill hot sell in 2011
1.adjustable particle size
2. over 20 years experience
3. all kinds of ores

                         steel rod mill hot sell in 2011



1.Main usages of rod mill



  applicable to wet fine and coarse grinding all kinds of ores and other materials , especially applicable to adjusting particle size in the process of production machine- made sand.



2. Working principle of rod mill:



  1.  The rod mill is a horizontal rotating device transmitted by the outer gear.



   2. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of ceramic ball in the chamber.



   3. The centrifugal force caused by rotation of barrel brings the ceramic ball to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.



3. Main technical parameters:



Model

Feeding size(mm)

Discharging size(mm)

Weight of ball(t)

Rotational speed (r/min)

Power(kw)

Capacity(t/h)

Weight(t)

Φ900*1800

≤20

0.075-0.89

1.4

42

18.5

0.65-2

3.6

Φ900*2100

≤15

0.075-0.83

1.7

41

15

0.7-3.5

3.9

Φ900*3000

≤20

0.075-0.89

2.5

41

22

1.1-3.5

4.5

Φ1200*2400

≤25

0.075-0.6

3.5

36

30

1.5-4.7

11.5

Φ1200*2800

≤25

0.075-0.6

4.5

36

37

1.5-5

13

Φ1200*4500

≤25

0.075-0.4

5.5

32

55

1.6-5.8

13.8

Φ1500*3000

≤25

0.047-0.4

8.68

31

75

2-7

17

Φ1500*3500

≤25

0.047-0.4

7.75-6.4

31

75

3-8.5

17.5

Φ1500*4500

≤25

0.047-0.4

10.5

27

110

3.5-8

21

Φ1500*5700

≤25

0.047-0.4

15

27

130

3.5-10

24.7

Φ1830*3000

≤25

0.047-0.4

18

26

160

4-12

28

Φ1800*3600

≤25

0.047-0.4

10.6-11.35

26

160

5-13

33.5

Φ1830*4500

≤25

0.047-0.6

12

26.5

185

5.5-20

35

Φ1830*7000

≤25

0.047-0.4

25

26

210

6.5-22

36

Φ2100*3600

≤25

0.047-0.4

14-15.2

24

185

15-30

46.8









NOTICE:ANY CHANGE OF THE TECHNICIAL DATA SHALL NOT BE ADVISED ADDITIONALY.





steel rod mill hot sell in 2011
