Specifications
MB rod ball mill exported to over 30 countries1. ISO9001:2000, CE
2. export to India, Asia, Mid-east, Africa
3. quality
MB rod ball mill exported to over 30 countries
1. rod ball mill working principle:
2. rod mill features:
1. can be used both dry and wet.
2. As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours.
3. The longer the ceramic mill runs, the finer the powder will be.
4. Our rod mill have been used to grind glass, powder food products, create custom varnishes, make ceramic glaze, powder various chemicals.
3. rod mill technical parameters:
Model | Diameter(mm) | Length(mm) | Feeding size(mm) | Final size(mm) | Capacity(t/h) | Power(kw) |
MB0918 | 900 | 1800 | <20 | 4.3 ~ 0.175 | 1.2 ~ 2 | 11 |
MB0924 | 900 | 2400 | <20 | 4.3 ~ 0.147 | 1.5 ~ 2.8 | 15 |
MB1224 | 1200 | 2400 | <25 | 4.3 ~ 0.175 | 3 ~ 7.5 | 30 |
MB1245 | 1200 | 4500 | <25 | 4.3 ~ 0.147 | 4 ~ 10 | 45 |
MB1530 | 1500 | 3000 | <25 | 4.3 ~ 0.175 | 10 ~ 25 | 75 |
MB1557 | 1500 | 5700 | <30 | 4.3 ~ 0.147 | 16 ~ 45 | 110 |
MB1835 | 1830 | 3500 | <30 | 4.3 ~ 0.175 | 40 ~ 60 | 130 |
MB1870 | 1830 | 7000 | <30 | 4.3 ~ 0.147 | 60 ~ 90 | 180 |
NOTICE:ANY CHANGE OF THE TECHNICIAL DATA SHALL NOT BE ADVISED ADDITIONALY.
1. The rod ball mill is a horizontal rotating device transmitted by the outer gear.
2. The materials are transferred to the grinding chamber through the quill shaft uniformly.
3.There are ladder liner and ripple liner and different specifications of ceramic ball in the chamber. The centrifugal force caused by rotation of barrel brings the ceramic ball to a certain height and impact and grind the materials.
4. The ground materials are discharged through the discharging board thus the grinding process is finished.
