Help CenterAnalog OscilloscopesGOS-620FG
US$ 1 - 1,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
GW Instek
Model Number:
GOS-620FG
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Analog Oscilloscopes GOS-630FCUS$ 1 - 1,000MOQ: 1 Piece -
Digital Storage Oscilloscopes GDS-300/200US$ 1 - 1,000MOQ: 1 Piece
-
Spectrum Analyzers GSP-9300US$ 1 - 1,000MOQ: 1 Piece
-
Real-Time & Digital Storage Oscilloscopes GRS-6000AUS$ 1 - 1,000MOQ: 1 Piece
-
Handheld Oscilloscopes GDS-122US$ 1 - 1,000MOQ: 1 Piece
Place of Origin
Taiwan, China
Brand Name
GW Instek
Model Number
GOS-620FG
Features
- Built-In 1 MHz Function Generator
- 20MHz Bandwidth, Dual Channel
- High Sensitivity 1mV/div
- ALT Triggering Function
- TV Synchronization
- CH1 Output
- Z-Axis Input
The GOS-620FG is a general purpose analog oscilloscope with 20MHz bandwidth. Aside from the basic functions such as 1mV/div~5V vertical sensitivity, 0.2uS/div~0.5S/div horizontal sweep time, and practical Auto/Norm/TV-V/TV-H trigger modes, the GOS-620FG offers extra Function Generating which is required by most class experiments and production lines. The GOS-620FG is also capable of generating Sine/Square/Triangle waveforms in 0.1Hz~1MHz (7 range) frequency range with sine wave distortion as low as 2%.
| GOS-620FG | |
| Digital / Analog | Analog |
| Display | 6" CRT |
| Bandwidth (MHz) | 20 |
| Number of Channel | 2 |
| Vertical Sensitivity | 1mV ~ 5V |
| Time Base Range | 0.2μs ~ 0.5s |
| Input Impedance Selection | 1MΩ |
| Auto Measurement | - |
| Waveform Memory | - |
| Panel Setup Memory | - |
| Auto-Set | - |
| Auto/Normal Trigger | V |
| ALT Trigger | V |
| TV Trigger | V |
| Cursor Readout | - |
| XY Mode | V |
| Zoom | - |
| Counter Function | - |
| Function Generator | V |
| Interface | - |
| Buzzer Alarm | - |
| Battery Power Operation | - |
| LED Indicators | - |
| Z-Axis Input | V |
| Power Source | AC 115/230V ±15% |
