YUMO S-320 320W 12/24/48V Single output High efficiency power supply Switching Power Supply
Specifications:
S-320 switch power supply,cctv psu
1.CCC CE RoHs approved
2.100% full load burn-in test
3. AC input selectable by switctch
Features:
1. AC input range selectable by switch
2. Protections: Short circuit / Overload / Over voltage / Over temperature
3. Forced air cooling by built-in DC fan
4. Cooling Fan ON-OFF auto control
5. 100% full load burn-in test
6. Fixed switching frequency at 90KHz
7. Low cost, high reliability
8. 18 months warranty
Model |
S-320-12 |
S-320-15 |
S-320-24 |
S-320-27 |
S-320-36 |
S-320-48 |
|
output |
DC voltage |
12V |
15V |
24V |
27V |
36V |
48V |
Voltage tolerance |
±1% |
±1% |
±1% |
±1% |
±1% |
±1% |
|
Rated current |
25A |
20A |
12.5A |
11A |
8.5A |
6.5A |
|
Current range |
0~25A |
0~20A |
0~12.5A |
0~11A |
0~8.5A |
0~6.5A |
|
Rated power |
300W |
300W |
300W |
297W |
306W |
312W |
|
Ripple&noise |
100mvp-p |
150mvp-p |
150mvp-p |
150mvp-p |
150mvp-p |
200mvp-p |
|
DCvoltage ADJ.range |
±10% |
±10% |
±10% |
±10% |
±10% |
±10% |
|
input |
Voltage range |
90~132VAC/180~264VAC(selected by switch),255~373VDC |
|||||
frequency |
47~63HZ |
||||||
AC current |
6.0A/115VAC,3.5A/230VAC |
||||||
efficiency |
80% |
80% |
82% |
82% |
82% |
83% |
|
Inrush current |
Cold start current 25A/115VAC,50A/230VAC |
||||||
Leakage current |
< 3.5mA/240VAC |
||||||
protection |
overload |
Rated output power105%~135% start over load protection |
|||||
protection type :rated current limit ,auto-recovery after fault condition is removed | |||||||
Over voltage |
15.6~17.8V |
18.6~20.8V |
30.6~33.2V |
33.2~35.6V |
42.6~44.2V |
54.8~56.6V |
|
Protection type:hiccup mode,auto-recovery after fault condition is removed | |||||||
Over temperature |
≥55℃fan on,≤50℃fan off,≥85℃ start over temperature protection |
||||||
Protection mode:cutoff output,auto-recovery after temperature become normal | |||||||
environment |
Working temp,humidity |
-10℃~+60℃,20%~90%RH |
|||||
Storagetemp,humidity |
-20℃~+85℃,10%~95%RH non-condensing |
||||||
Withstand vibration |
10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes |
||||||
safety |
Withstand voltage |
I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC |
|||||
Isolated resistance |
I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC |
||||||
Fitstandard |
Safety standard |
Fit UL1012 |
|||||
EMC standard |
EN55022,CLASSA |
||||||
others |
Dimension |
215*115*50mm (L*W*H) |
|||||
Weight/packing |
1.0kg/24pcs/25kg/0.049 m³/1.72CUFT |
||||||
note |
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. |
||||||
