S-200-24 Switching Power Supply
Low cost, high reliability, globally applicable AC input voltage, high efficiency, low temperature, soft-start current, effectively reduce the AC input impact, short-circuit protection, overload protection, small size, light weight 100% full load burn-in test, built-in EMI filters, small ripple
Model | S-200-5 | S-200-12 | S-200-15 | S-200-24 | S-200-36 | S-200-48 |
DC output voltage,current | 5V, 0-40A | 12V,0-16.5A | 15V,0-13.3A | 24V,0-8.5A | 36V,0-5.5A | 48V,0-4.2A |
Wave and noise | 150mVp-p | 150mVp-p | 180mVp-p | 180mVp-p | 200mVp-p | 200mVp-p |
Inlet wire stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Load stability | ±1% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Efficiency | 79% | 82% | 83% | 83% | 86% | 86% |
Adjustable range for DC voltage | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% |
Input voltage range | 90VAC-132VAC or 180VAC-264VAC | |||||
Impact current | Cold start current 15A/115VAC 30A/230VAC | |||||
Overload protection | 105%-201% cut off the out put,automation recovery | |||||
Over voltage protection | ||||||
Setup,rise,hold up time | 200ms,50ms,20ms/230VAC at full load | |||||
Withstand voltage | I/P-I/O:1.5kV I/P-FG:1.5kV I/O-FG:0.5kV one minute | |||||
Isolation resistance | I/P-I/O I/P-FG I/O-FG:500VDC/100MΩ | |||||
Working temperature | -10C~+50C | |||||
Dimension | 199*110*50mm | |||||
Weight | 0.9kg | |||||
S-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24VS-200-24 Switcing Supply Power 200W,24V
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
