YUMO S-400 400W 5/12/48V Single output High efficiency power supply Switching Power Supply
Specifications:
1.CE RoHS approved
2.2 years warranty
3.high quality
4.83% efficiency
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. 2 years warrenty ,buy with confidence
Features:
Model | S-400W-5V | S-400W-12V | S-400W-15V | S-400W-24 | S-400W-48 |
DC output voltage | 5V | 12 V | 15 V | 24V | 48V |
DC output current | 60A | 33A | 27A | 17A | 8.3A |
DC output voltage error | ±1% | ±1% | ±1% | ±1% | ±1% |
Ripple & noise | 150mV | 150mV | 150mV | 150mV | 150mV |
efficiency | 73% | 74 % | 78% | 81% | 83 % |
AC input voltage range | 85-132VAC/170-264vac 47-63HZ 240-370VDC | ||||
Input current | 6.5A/115V 4A/230V | ||||
AC inrush current | Cola-start current 25A/115V 50A/230V | ||||
Leakage current | <3.5mA/240VAC | ||||
DC adjustable range | ±10% rated output voltage | ||||
Over load protection | 105-135% cut off the output auto -recovery | ||||
Over-voltage protection | 115-135 cut off the output auto -recovery | ||||
Setup rise hold up time | 200ms 50ms 20ms | ||||
Withstand voltage | I/P-O/P:1.5KVAC 1minute I/P-FG:1.5KVAC 1minute O/P-O/P:0.5KVAC 1minute | ||||
Withstand temperature | -10°C~+60°C,20%-90% RH | ||||
weight | 1.05kg | ||||
