YUMO SE-600 600W 5/12/24/48V Single output High efficiency power supply Switching Power Supply
Specifications:
1. CE ROHS approved
2. AC110/220V input
3. 78% efficiency
4.2 years warranty
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. 2 years warrenty ,buy with confidence
General features:
MODEL | SE-600-5 | SE-600-12 | SE-600-15 | SE-600-24 | SE-600-27 | SE-600-48 |
DC VOLTAGE | 5V | 12V | 15V | 24V | 27V | 48V |
RATED CURRENT | 100A | 50A | 40A | 25A | 22.2A | 12.5A |
CURRENT RANGE | 0 ~ 100A | 0 ~ 50A | 0 ~ 40A | 0 ~ 25A | 0 ~ 22.2A | 0 ~ 12.5A |
RATED POWER | 500W | 600W | 600W | 600W | 599.4W | 600W |
RIPPLE & NOISE (max.) | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p |
VOLTAGE ADJ.RANGE | 4.75 ~ 5.5V | 10 ~ 13.5V | 13.5 ~ 16.5V | 22 ~ 26.4V | 24 ~ 30V | 43 ~ 56V |
VOLTAGE TOLERANCE | ±2.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% |
LINE REGULATION | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
LOAD REGULATION | ±2.0% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
SETUP, RISE, HOLD TIME | 1000ms, 50ms, 20ms/230VAC, 1000ms, 50ms, 50ms/115VACat full load | |||||
VOLTAGE RANGE | 90 ~ 130VAC / 180~260VAC selected by switch, 254~370VDC | |||||
FREQUENCY RANGE | 47 ~ 63Hz | |||||
EFFICIENCY (Typ.) | 78% | 83% | 84% | 87% | 87% | 88% |
AC CURRENT | 12A / 115VAC, 7.5A / 230VAC | |||||
INRUSH CURRENT (max.) | 25A / 230VAC, 50A / 230VAC | |||||
LEAKAGE CURRENT | <2.0mA / 240VAC | |||||
OVERLOAD | 110~135% rated output power | |||||
Protection type : Shut down o/p voltage, re-power on to recover | ||||||
OVER VOLTAGE | 5.75 ~ 6.3V | 13.8 ~ 16.2V | 18 ~ 21V | 27.6 ~ 32.4V | 31 ~ 36.5V | 57.6 ~ 67.2V |
Protection type : Shut down o/p voltage, re-power on to recover. | ||||||
OVER TEMPERATURE | 85ºC± 5ºC (TSW1) Detect on heatsink of power transistor | |||||
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down | ||||||
WORKING TEMP.,HUMIDITY | -20 ~ +60ºC (Refer to output load derating curve), 20 ~ 90% RH | |||||
STORAGE TEMP., HUMIDITY | -40 ~ +85ºC, 10 ~ 95% RH | |||||
TEMP. COEFFICIENT | ±0.05%/ºC (0 ~ 50ºC) | |||||
VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes | |||||
SAFETY STANDARDS | Design refer to UL60950-1 | |||||
WITHSTAND VOLTAGE | I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | |||||
ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC | |||||
MTBF | 197khrs min. MIL-HDBK-217F (25ºC) | |||||
DIMENSION | 247*127*63.5mm (L*W*H) | |||||
PACKING | 2.1Kg; 6pcs/13.4Kg/0.98CUFT | |||||
