YUMO SCN-1000 600W 12-48V Single output High efficiency power supply Switching Power Supply
Specifications:
1. CE ROHS approved
2. 220V input
3. 85% efficiency
4.2 years warranty
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. 2 years warrenty ,buy with confidence
General Features:
Model Performance | SCN-1000-12 | SCN-1000-13.5 | SCN-1000-15 | SCN-1000-24 | SCN-1000-27 | SCN-1000-48 |
DC Output Volta | 12V | 13.5V | 15V | 24V | 27V | 48V |
Output voltage tolerance(Note 2) | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
Rated output current | 50A | 44A | 40A | 25A | 22A | 12.5A |
Output current range | 0-40A | 0-36A | 0-32A | 0-20A | 0-18A | 0-10A |
Ripple and noise(Note 3) | 240mVp-p | 240mVp-p | 240mVp-p | 240mVp-p | 200mVp-p | 300mVp-p |
Inlet stability(Note 4) | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Load stability(Note 5) | ±1% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
DC output power | 600W | 600W | 600W | 600W | 600W | 600W |
Efficiency | 84% | 84% | 83% | 85.5% | 86.5% | 87% |
DC voltage adjustable range | 10-13.2V | 12-15V | 13.5-18V | 20-26.4V | 24-30V | 41-56V |
Input voltage range | 88~132VAC/176~264VAC CHOOSE BY SWITCH 47~63Hz;124~370VDC | |||||
Input current | 7A/115V 3.5A/230V | |||||
Surge Current | 0.95/100~240VAC | |||||
Leakage Current | 18A/115V 36A/230V | |||||
Overload protection | <3.5mA/240VAC | |||||
over-voltage protection | 105%~135% type:FOLDBACK cut off output reset:Automatic recovery | |||||
High temperature protection | 13.8~16.2V | 15.5~18.2V | 18~21V | 27.6~32.4V | 31~36.5V | 57.6~67.2V |
temperature coefficient | RTH1 OR RTH2>=55°C FAN ON,<=45°C FAN OFF,>=70°C cut off output | |||||
Start-up,upper,rentention time | ±0.03%°C(0~50°C) | |||||
shock resistance | 1.5s,50ms,20ms | |||||
Withstand | 10~500Hz,2G 10min./1circle,time:60min.,axes | |||||
Insulation Resistance | Input to Output Isolation:3KVAC,input&shell:1.5KVAC output &shell:0.5KVAC | |||||
work Temperature/ humidity | Input to Output Isolation,,input&shell, output &shell:500VDC/100M Ohms | |||||
Storage Temperature,temperature | -10°C~+50°C,20%~90%RH | |||||
Outline dimension | -20°C~+85°C,10%~95%%RH | |||||
Weight | 291*132*68mm shell:910 | |||||
Safety standards | 5Kgs | |||||
EMC Standard | UL1950,TUV EN60950 | |||||
Model Performance | CISPR22(EN55022),IEC1000-42,3,4,5,6,8,11 IEC100-3-2 | |||||
YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply
YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply YUMO SCN-1000 600W 12-27V Single output High efficiency power supply Switching Power Supply
YU
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed.
4. Solved the problem with you during using our products.
5. Samples will be offered to you for our future cooperation.
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
YUEQING YUMO ELECTRIC CO.,LTD
ADD: NO.126 LIUYANG ROAD ,ZHAOYANG INDUSTRY ZONE, LIUSHI TOWN,
YUEQING CITY, ZHEJIANG PROVINCE, 325604 CHINA
TEL:0086-577-62791815 Mobile:0086-13757779011
Sky-pe:benjaminying TradeManager:yncync
How to contact us:
Send your inquiry detail in the below for free samples, click "send "now.
Send Inquiry to This Supplier
