ALL CATEGORIES

Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Weichai Ricardo 125 KVA 100KW Diesel Generator Set

Weichai Ricardo 125 KVA 100KW Diesel Generator Set

Name: Weichai Ricardo 125 KVA 100KW Diesel Generator Set
Brand: Huatian
SKU: 141184396
Availability: InStock

Weifang Huatian Diesel Engine Co., Ltd.

US$ 1,000 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Huatian

Model Number:

125kva

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Huatian

Model Number 125kva

Output Type AC Three Phase

Speed 1500/1800 r/min

Frequency 50/60 Hz

Rated Power 100kw

Rated Voltage 400V

Rated Current 180A

Weichai Ricardo 125 KVA 100KW Diesel Generator Set

Product Description

Specification of genset
Gensets model				120GF
Prime power(KW)				120
Rated voltage(V)				400 / 230
Rated current(A)				217
Rated frequency(HZ)				50
Rated Speed (rpm)				1500
Power Factor				0.8(lagging)
Dimensions(mm) (L×W×H)				2450x930x1730
Genset Weight(kg)				1700
Specification of diesel engine
Engine brand				Weifang Huatian
Engine model				R6105IZLD
Air Intake System				Turbocharged
Fuel System				Direct Injection
Cycle				Four stroke
Cylinder Arrangement				6 in line
Displacement				7.01L
Bore×Stroke (mm×mm)				105 x 135
Rated RPM				1500rpm
Cooling System				Forced Water Cooling Cycle
Governor Type				Mechanical
Fuel Consumption at 100% Load (g/kwh)				238
Starting Method				DC24V electrical starting
Specification of alternator
Alternator brand				Chinese Stamford
Excitation				Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Number of Phase				3
Connecting Type				3 Phase and 4 Wires
Number of Bearing				1
Power Factor				0.8
Protection Grade				IP21
Altitude				≤1000m
Insulation Class, Temperature Rise				H
Telephone Influence Factor (TIF)				≤50
THF				≤2%
Voltage Regulation, Steady State				≤±1%
Transient State Voltage				≤-15%~+20%
Specification of control Panel
The control panel is common integrated control panel, with the display of voltage,current, frequency, water temperature, oil pressure.
