Weifang Factory 200KW ShangChai Diesel Generator With G128ZLD Engine
Technical Specifications | ||
Diesel Generator Set | Model No. | HT200GF |
Rated output(KW/KVA) | 160/200 | |
Standby output(KW/KVA) | 200/250 | |
Size(mm) | 2800*1100*1600 | |
Weight(KG) | 2500 | |
Diesel Engine | Model No. | G128AZLD |
Engine characters | water cooled, direct-injection,four stroke,inline | |
Rated output(KW/KVA) | 225/281 | |
Standby output(KW/KVA) | 247/309 | |
Cylinder NO. | 6 | |
Aspiration | Turbocharged | |
Bore(mm)*Stroke(mm) | 135*150 | |
Compression ratio | 13.5:1 | |
Displacement(L) | 12.88 | |
Start type | DC 24V electric start | |
Rated Speed(rpm) | 1500 | |
Rated fuel consumption(L/h) | ≤207g/kw.h | |
Alternator | Model No. | TZH-150 |
Continuous output(KW/KVA) | 300/375 | |
Voltage control | AVR | |
Excitation type | Brush/Brushless | |
Insulation class | H | |
Brand | Stanford/Stanford copy | |
Voltage(V) | 400/230 | |
Current(A) | 270 | |
Frequency(HZ) | 50HZ | |
Power Factor | 0.8 | |
Phase | 3-phases,4-wires | |
