Home > Products > Sea Water Pump > Electric high pressure end suction salty water pump
Electric high pressure end suction salty water pump
- 600 Set / Sets per Month
- Tianjin ( xingang )
- T/T Credit Card
You May Like
-
Seawater Reverse Osmosis system high pressure water pump
-
Centrifugal Electric Motor End Suction Marine Desalination Sea Water Pump
-
Brass Impeller High Pressure Marine Sea Water Pump
-
AQW contaminated water pump for trailings dam
-
Large Capacity Hydro Power Plant Double Suction Sea Water Pump
-
Duplex steel brine water pump Centrifugal horizontal multistage pump
Product Details
| Place of Origin | Hebei, China | Brand Name | AN PUMP | |
| Model Number | QI | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Hydraulic | Standard or Nonstandard | Standard | |
| Fuel | Other, electric salty water pump | Pressure | Other, high pressure salty water pump | |
| Application | Other, salty water pump |
Product Description
Electric high pressure end suction salty water pump
Brief introduction of Electric high pressure end suction salty water pump
QI series pump is single-stage , single-suction centrifugal pump , designed as per the interational standard ISO2858 . It is a replacement of type BA water pump which is applicable to industrial and urban water supply and discharge as well as the agriculture irrigation . It can be used to transport liquid which have physical and chemical properties similar to clean water with a temperature not exceeding 80°C.
Technical Datas of Electric high pressure end suction salty water pump
Type | QI |
Capacity (m3/h) | 3.5-1200 |
Head (m) | 3.7-128 |
Speed (r/min) | 1450-2900 |
NPSHr (%) | 2.0-7.5 |
Eff. (%) | 86-95 |
Weight (kg) | 33-1720 |
Dia Inlet (mm) | 50-300 |
Dia Outlet (mm) | 32-250 |
Electric high pressure end suction salty water pump Applications
It is mainly used in chemical, oil, petrochemical industry, metallurgy, light industry, printing dyeing, pharmaceutics, environment protect, seawater desalt, paper making, food and etc .industrial departments to transport corrosive medium without suspended grain or medium. Agricultural water supply, irrigation water supply, irrigation pump station.
Electric high pressure end suction salty water pump Features
Working Principle | Centrifugal |
Main applications | Water |
Driver | Electric motor, Diesel motor |
Power Specs | 380/415 V 3phase; 50hz/60hz etc. |
Max. permissible fluid temperature | 80°C /150°C |
Type of connection | Flange |
Installation position | Horizontal |
Casing/Inner parts material | Cast iron, Stainless Steel/Cast iron, Stainless steel, Bronze |
Shaft seal type | Mechanical seal, packing seal |
Electric high pressure end suction salty water pump Advantages
- 20 years in producing pumps
- Independent Design
- Advanced technology from Australia, Canada, America
- OEM available
- Specialized Test Equipment
- Anti-rust treatment casting
- Supply reasonable suggestion for choosing pumps
- Standard wooden cases package, if special requirements, should be inform in advance;
- Shipping by sea, by air, by train and truck all available;
- Delivery date: vary from 5-30days according to different model and quantity.
- 1 year guarantee of whole machine set, except the flow parts
- 24hours *7 days service is available
- Calling or door to door service
- User manual and maintenance instruction is available
Q1. Are you a manufacturer?
Yes, we have been in centrifugal pumps manufacturing and marketing industry over 32 years.
Q2. What markets do your pumps export to?
Europe, North & South America, SouthEast Asia, Africa, Oceanica, Middle East countries. Our overseas agent in Italy, Russia, Canada, France, America, Middle East, Asia and Africa are gradually improving.
Q3. What information should I let you know if I want to get a quotation?
Please let us know the pump capacity, head, medium, operation situation, quantity, etc. As much as your provide, the precision
and accurate model selection.
Q4. Is it available to print our own brand on the pump?
Totally acceptable as international rules.
Q5. How can I get the price of your pump?
You can connect with us through any of the following contact information. Our personalized service person will respond you within 24 hours.
