Brass Impeller High Pressure Marine sea water pump
~~~~~ OVERVIEW ~~~~~
Overview for Brass Impeller High Pressure Marine sea water pump
Model QS Sea water pump is a single-stage double-suction horizontal split centrifugal Sea water pump and used to transport sea water.
~~~~~ PARAMETER ~~~~~
Parameters about Brass Impeller High Pressure Marine sea water pump
Size:150-1200mm
Capacity:110-14400 m3/h
Head: 8.6-140 m
Speed:150-2900rpm
Materials:Stainless steel,Cast iron,Bronze etc
Coating: Preservative Treatment
~~~~~ APPLICATION ~~~~~
Applications about Brass Impeller High Pressure Marine sea water pump
The Sea water pump is widely used for seawter delivery, or as seawater desalination pump.
Large capacity centrifugal Sea water pump is the new products. It is specially designed by Shijiazhuang An Pump Machinery Company Designing group for the international sea projects, which is stonger anti-corrosive and anti-salt stmosphere.
|
~~~~~ FEATURES ~~~~~ 1. QS series large capacity Sea water pump matches the performance, technical requirement and testing method for the international sea projects. 2. The Sea water pump meet the international standard, with the feature of small volume, good performance, stable and reliable operation, and high efficiency. Besides, it is the best choice for the large flow fire projects. |
~~~~~ CONSTRUCTION ~~~~~
Construction about Brass Impeller High Pressure Marine sea water pump
~~~~~ PERFORMANCE PARAMETER ~~~~~
Performance Range about Brass Impeller High Pressure Marine sea water pump
Flow rate:112~14400m3/h
Head:11~100m
Speed:500~2900rpm
Max Eff:92%
~~~~~ PERFORMANCE TABLE LIST ~~~~~
Performance table list about Brass Impeller High Pressure Marine sea water pump
| Model | Flow rate |
Head |
Speed |
Power |
Eff |
Iimpeller |
Weight |
(QS) |
(m3/h) |
(m) |
(rpm) |
(KW) |
(%) |
(mm) |
(kg) |
QS150 |
110~220 |
35~84 |
2900 |
30~55 |
67~80 |
186~250 |
145~150 |
QS200 |
160~351 |
31~100 |
2900 |
37~110 |
61~85 |
193~284 |
219~265 |
QS250 |
324~612 |
8.6~71 |
1450 |
22~132 |
72~86 |
224~460 |
405~565 |
QS300 |
504~972 |
8~98 |
1450 |
30~300 |
70~84 |
225~540 |
845~660 |
QS350 |
745~1663 |
10~140 |
1450 |
55~680 |
70~88 |
270~655 |
760~1580 |
QS400 |
900~1620 |
32~98 |
980~1480 |
155~500 |
71.5~84 |
510~535 |
1910 |
QS500 |
1150~2450 |
10.6~108 |
740~970 |
110~800 |
70~89 |
390~860 |
2000~4330 |
QS600 |
2304~4000 |
13~80 |
730~970 |
185~900 |
70~91 |
450~830 |
2500~4300 |
QS700 |
2111~4896 |
39.5~99.5 |
740~980 |
560~1250 |
52~92 |
415~850 |
5800 |
QS800 |
3960~7200 |
23.5~84 |
600~740 |
450~1600 |
77~92 |
715~990 |
5100~8300 |
QS1000 |
6000~9900 |
32~52 |
600~990 |
1250 |
79~87 |
670~695 |
10000 |
QS1200 |
5832~14400 |
6~95.7 |
500~745 |
710~3450 |
80~90 |
560~1200 |
12500~16000 |
~~~~~ PACKAGING & SHIPPING ~~~~~
Brass Impeller High Pressure Marine sea water pump standard packing and shipping ways:
Outside: Standard fumigated wooden case
Inner: Stretch film
Bottom: Wooden pallet
~~~~~ OTHER RELATED PRODUCTS ~~~~~
Other suggested products?
Other models of sea water pump:
|
|
|
