Cast Iron Diesel Engine Water Fire Fighting Pumps

Cast Iron Diesel Engine Water Fire Fighting Pumps thumbnail-3

Cast Iron Diesel Engine Water Fire Fighting Pumps thumbnail-4

Cast Iron Diesel Engine Water Fire Fighting Pumps thumbnail-5

Cast Iron Diesel Engine Water Fire Fighting Pumps thumbnail-6

Cast Iron Diesel Engine Water Fire Fighting Pumps photo-1

Cast Iron Diesel Engine Water Fire Fighting Pumps photo-2

Cast Iron Diesel Engine Water Fire Fighting Pumps photo-3

Cast Iron Diesel Engine Water Fire Fighting Pumps photo-4

Cast Iron Diesel Engine Water Fire Fighting Pumps photo-5

Cast Iron Diesel Engine Water Fire Fighting Pumps photo-6

US$ 998 - 7,850 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Y&L

Model Number:

TPOW

Contact Supplier Request Quote Chat Now

Shanghai Y&L Pump Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name Y&L

Model Number TPOW

Theory Centrifugal Pump

Structure Single-stage Pump

Usage Water

Power Electric

Standard or Nonstandard Standard

Fuel Diesel

Pressure Low Pressure

Application Other, Fire Fighting

Cast Iron Diesel Engine Water Fire Fighting Pumps

Product Description

TPOW series double suction centrifugal water pump is single-stage double-suction split volute casing centrifugal pump and is specially designed and manufactured by our company which based on the market requirement and introducing in German lead technology. Pump through original impeller and modified impeller and cutting, the pump is with full and broad, high efficiency. In the performance scope, according to consumers’ needs, may provide pump with any flow and head.

Specification

>>>Working Condition

Model: TPOW series double suction split case centrifugal pump

Structure: horizontal, single stage, double suction, split case

Size: 3inch to 32inch

Max. Capacity: 11660 m3/h

Max. Head: 230 m

Rotation Speed: 590-2950 r/min

Shaft Power: 1.2-3418.8 kw

Max. Working Temperature: 105 ℃

Shaft Seal: Mechanical Seal or Packing Seal

Pump Material: Cast Iron, Stainless Steel 304/316/316L

Impeller Material: Cast Iron, Copper, Stainless Steel 304/316/316L

>>>Parameter Table

TPOW Performance Parameters
Pump Model	Capacity (m3/h)	Head (m)	Speed (r/min)	Shaft Power (kw)	Impeller's Dia (mm)	Net Pump Weight (kg)

TPOW80-220	17	16	1480	1.9	215	181
	66.5	12.8		2.9
	108	7.8		3.3
TPOW80-220	60	58	2950	24.3	215	181
	134.5	51		23.1
	162	46		29.4
TPOW80-280	22	25.9	1480	3.3	275	194
	86	20.7		6.3
	112	16.5		7.2
TPOW80-280	60	95	2950	33	275	194
	172	82.5		50.2
	210	73		60.1
TPOW80-350	26	37	1480	4.9	348	204
	100	35.5		13.2
	132	27.9		14.2
TPOW100-260	30	21.7	1480	4.3	254	207
	123.5	17		7
	170	12.5		8.1
TPOW100-260	52	81	2950	27.6	254	207
	245.5	68		55.8
	288	60		59.2
TPOW100-300	100	128	2950	56.2	285	200
	160	121		73.2
	200	110		86.8
TPOW100-320	50	36	1480	11.7	325	223
	141.5	29.5		14.6
	174	25.5		17.3
TPOW100-320	70	141	2950	64	325	223
	283	119		117.6
	324	108		126.2
TPOW100-400	60	56	1480	22.3	408	241
	163	52		32.1
	187.2	45		33.2
TPOW125-240	100	20.2	1480	10.9	245	310
	256.5	15.1		12.5
	320.1	10.8		12.4
TPOW125-240	111	78	2950	51.8	245	310
	472.5	60.5		92.1
	540	50		90.8
TPOW125-300	100	32	1480	17.1	301	350
	242.5	25		19.9
	370	17.1		24.1
TPOW125-300	230	113	2950	120	301	350
	479	100		157.2
	558	92		181.6
TPOW125-400	160	178	2950	129.3	334	460
	260	166		170.3
	310	153		195.7
TPOW125-450	280	233.5	2950	287.2	391	500
	440	225		396.5
	500	220		443.8
TPOW125-480	100	72	1480	46.7	475	500
	294.5	69.5		70.6
	342	64		78.4
TPOW125-570	250	110.5	1480	123.3	521	700
	400	107		166.5
	470	104		194.3
TPOW150-280	140	26	1480	23.1	289	347
	397	20.4		25.6
	450	18		26.6
TPOW150-310	310	33	1480	36.2	318	400
	350	29.5		35.1
	406	27		37.8
TPOW150-350	150	41	1480	32.8	355	410
	407.5	35		46.2
	468	32		49.7
TPOW150-450	150	67	1480	66.8	454	520
	440	60		88.8
	582	47		101.4
TPOW150-570	200	103	1480	130.5	560	740
	537	90		166.6
	620	81.9		194.8

More model, Please contact me.

Features

1) Technical Characteristic:

straight line design
both sides of supporting away from short, the corresponding axis is also short
Convenient installation, automatic correction pump cover

2) High Performance Impeller:

Double suction impeller make shaft force to the lowest degree
Replaceable impeller seal-ring
Has the outstanding water power performance impeller

3)Shaft Service Convenient:

Complete sealed, do not need contact the medium, and no corrosion
Short and fine rigidity, no vibration
With replaceable shaft’s sleeve

Application

Constructional engineering: Clear water transportion,pressurization system,air

condition water,circulation system,fire extinguishing system,swimming pool and water circulation system.
Industry : circulating cooling system ,process water for papermaking and paper pulp,steel production,shipbuilding,sea trasportion,and other mafacturing industry.
Mini industry : water supply,mine drainage,generating station,ect.
Other: municipal water supply,agricultural irrigation,and some others.
Water drainage station
Seriously polluted water discharge
Agricultural irrigation, transfer water ,etc.

Our Services

1. Delivery: Delivery time will be on time as the contract. Usually, the delivery time of pump is 7-15 working days.

2. Warranty: 1 year for the pump body, 3months for the main working parts.

3. Package: According to your quantity, we use strong carton or plywood case which is durable for ocean transport.

4. Shipping: By Sea or By Air.

5. Payment: we can accept T/T, L/C, West Union and so on.

6. Pre-sales Service: According to your requirement, we will give you our profession advice of pump solution.

7. On-sales Service: We will clearly show you everything in fact when you place an order with us. We will takes photos or videos to show you our production situation.

8. After-sales Service: We will full report you the production progress and plan. Meanwhile, we will follow up the pump working conditions per three months when the pumps put into use, and can send the spare parts to you within one week if u need.
