Universal Knee Type Milling Machine

Universal Knee Type Milling Machine thumbnail-1
Universal Knee Type Milling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
Used
Place of Origin:
Shandong, China
Brand Name:
EAGLE
Contact Supplier Request Quote Chat Now
Eagle Industries, Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition Used
Place of Origin Shandong, China
Brand Name EAGLE
Model Number UTM 360
Type Vertical
CNC or Not Normal

Specifications

Universal Knee Type Milling Machine
1. CE Electrical Par
2. Table Size: 1220x360mm
3.High precision.
4.Good quality.

Universal Knee Type Milling Machine

Specification



-UTM 360, Automatic feeds on X,Y axes





-UTM 360A, Automatic feeds on X,Y,Z axes





-UTM 360B, Automatic feeds on X,Y,Z axes and 1000mm table travel on axis













MODEL

UNIT

UTM 360

UTM 360A

UTM 360B

Spendle tapre



724  ISO50

Distance from spindle axis to column

mm

70-515

60-420

60-430

Distance from spindle nose to table

mm

325

360

Range of  spindle speed

r/min

60-170012steps

60-169012steps

Swivel angle of vertical milling head



±45°

Table size

mm

1220×360

Table travel(H/C/V)

mm

600/250/400

600/320/360

1000/340/370

Range of  lingitudinal,cross travel

mm/min

24-7208steps       1080rapid

30-7408steps                                         1080rapid

Z speed of table

m/min

-------

590

T-slot of table (unmber-width-length)

mm

3/14/95

3/18/80

Main motor

kW

4

Motor for rapid device of table(X,Y)

W

Optinal:X,Y power speed

750

Motor for vertical device of table(Z)

W

---------

750

N.W,G.W.

kg

1900/2100

2200/2400

Overall dimension

mm

1800×1850×1880

1700×1680×1880

Item No.



131305

131306

131307



standard accessories



Optional accessories:





Mill collets



Digital redout sytem(DRO)





draw bar



Clamping kits





machine vise



Rotary worktable





coolant system



Dividing head





work lamp









table elevating motor









convergent panel









wrench









spanner









middle sleeve









elevating rotary handle









oil collecting plate









operation manual
