Bench Mill Drill

Name: Bench Mill Drill
Brand: Eagle
SKU: 140924634
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

Used

Place of Origin:

Shandong, China

Brand Name:

Eagle

Eagle Industries, Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition Used

Place of Origin Shandong, China

Brand Name Eagle

Model Number BMD16

Type Horizontal

CNC or Not Normal

Voltage 220V

Power(W) 500W

Dimension(L*W*H) 720*650*870mm

Weight 127/140kg

After-sales Service Provided No overseas service provided

Specifications

Bench mill drill
1.Advanced 500W brushless motor
2.Variable speed range 50-2,500rpm

Key Feature

Specifications

Drilling capacity	16 mm
Max. tapping capacity	20 mm
Face mill capacity	30 mm
Longitudinal axis (X)	230 mm
Cross aixs (Y)	150 mm
Headstock travel (Z)	220 mm
Max distance spindle to table	300 mm
Spindle taper	MT2
Spindle speed (variable speed)	50-2500 ±10% rpm
Table effective size	500×130mm
T-slot size	8 mm
Head tilt	45°L, 45°R
Motor output power	500 W
Overall dimension (LxWxH)	630x830x810 mm
Packing size (LxWxH)	720x650x870 mm
Weight (Net/Gross)	127/140 kg
Model	BMD16
Item Number	100124

Standard attachment

13mm drillchuck

Wrtnch set

Oil can

OPTIONAL ACCESSOTIES

S/N:10228	Stand
S/N:10228	Overall dimension:530×610×850mm
S/N:10104	Clamping kit 12 pcs
S/N:10104	Bolt size 6mm
S/N:10105	Clamping kit 24 pcs
S/N:10105	Bolt size 6mm
S/N:10117	Boring arbor with boring cutter
S/N:10117	MT#2
S/N:10118	Stub milling machine arbor
S/N:10118	hole 13mm
S/N:10116	Stub milling machine arbor
S/N:10116	hole 13mm
S/N:10108	Vice width 55mm
S/N:10133	VICE width 40mm
S/N:10035	Quick vice 50mm
S/N:10038	2 Flute Hss end mill 4mm
S/N:10039	2 Flute Hss end mill 6mm
S/N:10040	2 Flute Hss end mill 8mm
S/N:10041	2 Flute Hss end mill 10mm
S/N:10067	2 Flute Hss end mill 3mm
S/N:10068	2 Flute Hss end mill 5mm
S/N:10069	2 Flute Hss end mill 3-10mm set
S/N:10070	Mill chuck set(6 PCS)
S/N:10070	Chuck dia. 3, 4, 5, 6, 8, 10mm
S/N:10071	Indexable carbide end mill
S/N:10071	MT#2 Dia.16mm
