Vertical Drilling Machine

Eagle Industries, Ltd.
Vertical Drilling Machine thumbnail-1
Vertical Drilling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Drilling Speed:
0.08,0.16,0.24mm/r
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Drilling Speed 0.08,0.16,0.24mm/r
Place of Origin Shandong, China
Brand Name EAGLE
Model Number DVZ 25 DVZ 25A
Voltage 380v
Power(W) accroding to custom
Dimension(L*W*H) 640x470x1670mm
Weight 243KGS/299KGS 254KGS/310KGS
Certification IEC
After-sales Service Provided No overseas service provided

Specifications

Vertical Drilling machine
Change speed with gears and operate easily
High spindle speed and wide speed range

Vertical Drilling machine

Specification



Features

Change speed with gears and operate easily
High spindle speed and wide speed range
Characteristic auto tool releasing device guarantees it is very easy to change tool.
The worktable can be rotated and operated easily
The worktable can rotated 360° or leaned ±45° and operated easily(only for DVZ25A)

Electrical system conforms with IEC standards
This machine can be used drilling,core drilling,reaming, boring,tapping,spot-facing and chamfering etc.



Specifications

Drilling vertical  machineDVZ 25 DVZ 25A
Max. drilling diameter(steel)25mm(1in)
Max. spindle travel140mm(5 1/2)
Taper of spindle boreMorse No.3
Distance from the center of spindle to the surface of the vertical column225mm(8 7/8in)
Max. distance from spindle nose to the surface of worktable 620mm(24 1/2in)600mm(23 5/8in)
Feed range of spindle 0.08,0.16,0.24mm/r
Max.travel of the bracket of worktable390mm(15 3/8in)412mm(16 1/4in)
Max. distance from spindle nose to base plate1075mm(42 5/16in)
Diimensions of effective working area of workableΦ390mm(Φ15 3/8in)275x315mmm(10 13/16x12 7/16in)
Spindle speeds range(8steps)100-2900r/min
Motor power0.75/0.55kw
Overall dimension640x470x1670mm(25x18 1/2x66 6/8in)
Package dimensions(LxWxH)1800x510x880mm(70 7/8X20 1/16X34 5/8in)
N.W./G.W.243KGS/299KGS254KGS/310KGS
Item No.412035412036
