UM 30 Series Universal Turret Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
Used
Place of Origin:
Shandong, China
Brand Name:
EAGLE
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
Used
Place of Origin
Shandong, China
Brand Name
EAGLE
Model Number
UM 30
Type
Universal
CNC or Not
Normal
Voltage
380~415V
Power(W)
2.25~5kw
Dimension(L*W*H)
1516*1550*2080mm
Weight
1400~1600kg
Certification
CE
Warranty
one year
Specifications
UM 30 series Universal Turret Milling Machine1.CE certificate
2.ISO certification
3.Easy operation
4.Perfect painting
UM 30 series Universal Turret Milling Machine
Specification
UM30 : rectangular guideway is adopted both on Y-and Z-axis.The guideway on saddle is lined with TF weatable material.Which makes the machine stably and rigidly. Also makes it beautiful and easy to operate.
UM 30A : fixed struture is used to connect the mill head without addapter.Which makes the cut intensity well. Rectangular guideway on Y-and Z-axis makes the machine stably and rigidly.The guideway on saddle is lined with TF wearable material.
| Model | Unit | UM 30 | UM 30A |
| Table size | mm | 305×1370(12''×54') 305×1500(12''×60'') | |
| Long travel | mm | 870 1000 | |
| Cross travel | mm | 380 | |
| Vertical travel | mm | 430 | |
| T-slot NO.and size | mm | 3×16 | |
| Ram travel | mm | 500 | |
| Distance from spindle nose to table surface | mm | 0~435 | |
| Spindle hole taper | MT | (standard):ISO40 | |
| Spindle travel | mm | 127 | |
| Spindle speed | Rpm | standard:shiftgrade 50HZ 65~4500 60HZ 80~5440 optional: wariable 65~3750 | |
| Auto quill feed | mm/rev | threesteps: 0.04(0.0015'') 0.08(0.003") 0.15(0.006") | |
| Spindle motor | kw/HP | 3.75/5 | |
| Head swivel | º | 90 | |
| Head tilting | º | 45 | FIX |
| One mille rper case | mm | 1566×1650×2080 | |
| Two mille rper case | mm | 1720×1800×2175 | |
| Gross weight | kg | 1700 | 1750 |
| Item NO. | 131080 131081 | 131090 131091 | |
| Standard accessory | Optionala ccessory | |||||
| Draw bar | Digital readout | R8 collet chuck and collets | ||||
| Electrical box | Machine vise | Oil colledting plate | ||||
| Working lamp | Power feed unit | Plastic splash guard | ||||
| Handle oil pump | Universal clamping apparatus | Cooling system | ||||
| Tools and tool box | NT30.NT40collet chuck | Gear box power feed | ||||
| Slotting head | ||||||
