Automatic Level Laser Machine AL 24
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Laser Type:
Diode
Place of Origin:
Shandong, China
Brand Name:
EAGLE
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Laser Type
Diode
Place of Origin
Shandong, China
Brand Name
EAGLE
Model Number
AL 24
Specifications
Automatic Level Improved structure of rack and gear system avoid dislocationReliable air-damping, wire-hung compensator with X
| Automatic Level | |
| AL 24 | |
| Features: | |
| Improved structure of rack and gear system avoid dislocation. | |
| Reliable air-damping, wire-hung compensator with X wire design. | |
| Excellent sealed structure for using in any weather conditions. | |
| 5/8"X11 threads to fit standard tripod, suitable for both flat and dome head tripod. | |
| Item | Specifications |
| Magnification | 24X |
| Standard deviation for 1km | 2.0mm |
| Double run leveling Objective Aperture | 38mm |
| Field of View | 1°20' |
| Shortest Focus Distance | 0.3m |
| Compensator type | wire-hung and air-damping |
| Working range of compensator | ±15' |
| Levelling accuracy | ±0.5" |
| Circular vial | 8'/2mm |
| Horizontal circle | 360°or 400G for option. |
| Weight | 1.65kg |
| Standard outfit | Auto Level, plumb bob, adjusting wrench, instruction manual, plastic carrying case. |
| Item NO. | 781011 |
