china cheaper 1250mm FSK laminator supplier

Specifications

FSK laminator
1.1250mm,diamond type
2. laminator once time
3.foil ,scrim and coated kraft

FSK laminator

1.1250mm,diamond type
2. laminating once time
3.foil ,scrim and coated kraft



FSK laminator

1.PRODUCTION FROM THIS MACHINE

  1.FSK (16mm, flat prismatic type);

  2.aluminum foil with coated PE paper(max 200 gsm) ;

  3.Finally production size:1250mm;

  4.machine speed :10m/min;

  5.machine weight:4200kgs;

  6.machine size:8800x4000x2100mm.

2.DETAIL INFORMATION

1 .Unwind diameter:1000mm

2. Rewind diameter with steel wall:800mm

3. Al foil diameter:500mm

4. Paper unwind controlled by magnetic powder controller:20kg

5. Al foil unwind controlled by magnetic powder controller:10kg

6. Take up unit motor:5.5kw

7. Rewind torque motor:100N

8. Paper unwind air shaft:3”

9. Al foil unwind air shaft:3”

10. Rewind air shaft:3”

11. Take up heater roller:320x1350

12. Take up pressure rubber roller:240x1350

13. Cooling roller:240x1350

14. Round knife:105/75

15. Waster slitting blower:3kw

16. Silicon al metal Guider roller:80x1350

17. Air cylinder:120x100

18. Tool:1 set

19. Fiber knife(with nip):2 sets

20. Heater pipe:10pcs



3.Spare part:

1. Heater:15pcs

2. silicon roller:1pc

3. chain linked board for netting:100 pcs

4. needle for machine run:100 pcs
