Specifications
extrusion laminating machine1.non-woven fabric
2.five roller
3.friction rewind
4.supply material
extrusion laminating machine
1.manual or auto unwind
rona treatment
3.auto or manual rewind
Detail of extrusion laminating machine
No | Character | Specification |
1 | Screw and barrel | 65/90/120mm,38CrMoAl hardness treatment with Nitride |
2 | L/D | 32:1 |
3 | T-die | new type featheredge mould5CrNiMoV |
4 | Gear box | high strength hard teeth retarder |
5 | Extruder number | One set |
6 | temperature control system | Digital type |
7 | Web request | 30gsm-350gsm |
8 | Coating material | PE,PP |
9 | Thickness of coating | 0.012-0.035mm |
10 | Coating width | 800-2000mm |
11 | Symmetrical degree of coating | ±6% |
12 | Peel off strength | 3-5N/30mm Depend on web material |
13 | extruder capacity | 80-220kg/h |
14 | Design machine speed | 0-180m/min |
15 | Unwind type | Simple one |
16 | Rewind type | Auto change roller |
17 | rewind and unwind diameter | 800mm-1200mm |
18 | pneumatic roller | 3” |
19 | Total power | about 135 Kw |
20 | Overall size (L×W×H): (mm) | 8500×8500×3000 |
21 | Weight | 18000kg |
22 | Corona treatment | One set |
23 | Side waster slitting device | Two sets |
buyer list of
extrusion laminating machine
:JAPAN , PAKISTAN , IRAN TURKEY
Certificate supply:SGS ,C/O,CE,FTA and so on
Key parts warrantee time of extrusion laminating machine
:
No | Part | Warrantee time |
1 | T-DIE | 12 month |
2 | Silica roller | 3 month |
3 | laminating roller | 12 month |
4 | Screw and barrel | 24 month |
5 | PLC system | 12 month |
6 | inverter | 18 month |
Key parts brand list of
extrusion laminating machine
No | Part | China Or over Country brand |
1 | Braker motor | Germany |
2 | Inverter motor | USD |
3 | Inverter | CHINA BEST |
4 | Encoder | JAPAN |
5 | Air cylinder | Taiwan |
6 | PLC mould | JAPAN |
7 | T-die(Steel material) | CHINA BEST |
8 | Temperature meter | JAPAN |
9 | Tension controller | JAPAN |
10 | Human inteface | Taiwan |
11 | Contactor | France |
12 | Air parts | France |
13 | Lower friction air cylinder | Italy |
Non-Woven fabric Extrusion laminating machine, Non-Woven fabric Extrusion laminating machine supplier, Non-Woven fabric Extrusion laminating machine manufacture, China Non-Woven fabric Extrusion laminating machine, sale Non-Woven fabric Extrusion laminating machine, export Non-Woven fabric Extrusion laminating machine , Non-Woven fabric Extrusion laminating machine price
