Help CenterHIGH QUALITY PNEUMATIC TYRE UNION
Related Products
-
Figure2002 2202 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces -
Figure 1502 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces
-
Figure 1002 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces
-
Figure 1003 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces
-
Figure 602Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces
Pneumatic tyre union is widely used in the pipeline with low pressure,large drift diameter and misplacement, and frequent mounting and dismantling, particularly in the connection between the mud tanks of the solid control system in the petroleum sector.
Product construction: steel shell and pneumatic tyre
Operating environment: -45℃-50℃
Max. sealing pressure (fluid pressure in the pipeline):0.4MPa
Return time of pneumatic tyre when deflated: 1-3 sec.
The connecting pipe may be in glass-reinforced plastic pipe or hose with connectors at the ends. The glass-reinforced plastic pipe is corrosion-resistant and light for easy handling. The rubber pipe is easy for bending and suitable for field mispiacement installation of pipeline.
Product specification
Sizes(in/mm) |
Applicable pipe diameter(mm) |
Dimension of crater(mm) |
4"(φ100) |
φ116 |
φ165 |
8"(φ200) |
Φ219 |
φ273 |
10"(φ250) |
Φ273 |
Φ325 |
12"(φ300) |
Φ325 |
Φ377 |
14"(φ350) |
Φ380 |
Φ428 |
1. Your inquiry related to our products or prices will be replied in 12 hours.
2. Well-trained and experienced staffs to answer all your inquiries.
3. Protection of your sales area, ideas of design and all your private information
standard package or according to customers needs
